TECHNICAL SPECIFICATIONS

ITEM
Nominal power
Rated Voltage
Rated Amperage
Batteries
Scrub Brush Motors
Vacuum Motor
Propelling Motor
Mass (GVW)
Weight empty without batteries
Solution Control
Solution tank capacity
Recovery tank capacity
Scrub brush diameter for 36 in. (90 cm) scrub head
Scrub brush pressure
Scrub brush speed
Tires
Casters
Foundation Pressure (at recommended tire psi)
Maximum Speed
Coverage with 36 in. (90 cm) scrub head
Frame Construction
Brakes
Minimum aisle u-turn width with 36 in. (90 cm) scrub head
Maximum rated climb and descent angle with empty tanks
Maximum rated climb and descent angle with full tanks
* Cleaning rate results will vary depending on floor type, building structure, etc.
3-1
SCEX364 86037160 03/12/07
DIMENSION/CAPACITY
1440 Watts
24VDC
60 Amps
4 X 6 Volt 250-305-335AH @ 20
hr rate
.33 hp (0.25 Kw)
.75 hp (0.56 Kw)
.3 hp (0.22 Kw)
956 pounds (433 kg)
395 pounds (179 kg)
Gravity feed, fully variable with
automatic shut-off in neutral
23 gal. (87 l)
25 gal. (95 l)
12 in (30.0 cm)
Actuated 0 lbs to 150 lbs (0 kg to
68 kg)
165 rpm
2 x 10 in (25.4 cm) non-marking
foam-filled
2 X 4 in (10.2 cm) polyurethane
solid non-marking
48 psi
3.2 Miles/hour (5.2 km/hour)
277 sq. ft/min
Steel plate with epoxy
powdercoat finish.
Tire lock parking brake.
73" (185 cm)
2%
2%
