WALK BEHIND SCRUBBER
MODELS:
SC20
10052190
SC20T
10052200
SCX20T
10052370
Bitte lesen Sie diese Anleitungen, bevor Sie die Maschine in Gebrauch nehmen
BA
86038350 01/29/07
PRV NO. 98712
SCC20
10052230
SCC20T
10052240
SCXC20T
10052420
Read these instructions before using the machine
Operating Instructions
Bedienungsanleitung
IPX4
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Windsor Saber Compact SC20
Summary of Contents for Windsor Saber Compact SC20
- Page 1 WALK BEHIND SCRUBBER MODELS: SC20 10052190 SC20T 10052200 SCX20T 10052370 Bitte lesen Sie diese Anleitungen, bevor Sie die Maschine in Gebrauch nehmen 86038350 01/29/07 PRV NO. 98712 SCC20 10052230 SCC20T 10052240 SCXC20T 10052420 Read these instructions before using the machine Operating Instructions Bedienungsanleitung IPX4...
-
Page 2: Machine Data Log/Overview
Copyright 1995 Windsor Industries, Printed in USA Name: __________________________________________________________________________________________________ Address: _______________________________________________________________________________________________ For the name and address of your dealer contact: Windsor Industries Phone Number: _________________________________________________________________________________________ The Saber Compact is a battery powered, hard floor scrubber intended for commercial use. The appliance applies a cleaning solution onto a hard floor, scrubs the floor with a brush or pad, and then vacuums the soiled water back into the recovery tank. -
Page 3: Table Of Contents
Machine Data Log/Overview...2 Table of Contents...3 HOW TO USE THIS MANUAL How to use this Manual...1-1 SAFETY Important Safety Instructions ...2-1 Hazard Intensity Level..2-2 Safety Label Location..2-3 OPERATIONS Technical Specifications..3-1 How the Machine Works..3-3 Components...3-4 Controls...3-5 Machine Operation... -
Page 4: How To Use This Manual
The HOW TO USE THIS MANUAL section will tell you how to find important information for ordering correct repair parts. Parts may be ordered from authorized Windsor dealers. When placing an order for parts, the machine model and machine serial number are important. -
Page 5: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When using an battery powered appliance, basic precaution must always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING THIS MACHINE. WARNING: To reduce the risk of fire, electric shock, or injury: Use only indoors. Do not use outdoors or expose to rain. Use only as described in this manual. -
Page 6: Hazard Intensity Level
WHEN SERVICING MACHINE: Avoid moving parts. Do not wear loose clothing; jackets, shirts, or sleeves when working on the machine. Use Windsor approved replacement parts. WARNING Batteries emit hydrogen gas. Explosion or fire can result. Keep sparks and open flame away. Keep solution tank in raised position when charging. -
Page 7: Safety Label Location
NOTE: These drawings indicate the location of safety labels on the machine. If at any time the labels become illegible, promptly replace them. CAUTION Explosive Gas is Given Off By Batteries During Charge. 1. Keep Battery Compartment Cover Open. 2. No Smoking, Flame Or Sparks In Area. -
Page 8: Technical Specifications
TECHNICAL SPECIFICATIONS ITEM Nominal power – non-traction model Nominal power – traction model Rated Voltage Rated Amperage – non-traction model Rated Amperage – traction model Batteries Scrub Brush Motor Vacuum Motor Propelling Motor – traction model Mass (GVW) – non-traction model Mass (GVW) –... -
Page 9: Special Notes
ITEM Height Length Width without squeegee Width of squeegee Width of scrub path Length SPECIAL NOTES: The A-weighted sound pressure level emitted by the appliance was measured to be 72.5 dBA. This is a space-averaged, broad-band measurement determined according to IEC 704-I. -
Page 10: How The Machine Works
HOW THE MACHINE WORKS The Saber Compact is a battery powered, hard floor scrubber intended for commercial use. The appliance applies a cleaning solution onto a hard floor, scrubs the floor with a brush, and then vacuums the soiled water back into the recovery tank. -
Page 11: Components
COMPONENTS 1. Control Panel 2. Control Handle 3. Recovery Tank 4. Recovery Tank Drain Hose 5. Scrub Head 6. Scrub Brush Access Cover 7. Solution Tank 8. Solution Tank Cover 9. Solution Tank Drain Hose 10. Solution Strainer 11. Solution Tank Support Arm 12. -
Page 12: Controls - Non-Traction
CONTROLS – NON-TRACTION 1. Brush Switch 2. Brush Lift Lever 3. Vacuum Switch 4. Squeegee Lift Lever 5. Solution Control Lever 6. Battery Charge Level Indicator 7. Hour Meter (Optional) 8. Circuit Breakers SABER (SC) 86038350 01/29/07... - Page 13 1. BRUSH SWITCH Controls the scrub brush motor. To turn scrub brush on, press the top of the switch. To turn scrub brush off, press the bottom of the switch. 2. BRUSH LIFT LEVER Raises and lowers the brush. To lower the brush, lift the lever from the notch, move to the left, then lower.
-
Page 14: Controls - Traction
CONTROLS - TRACTION 1. Solution Control Knob 2. Brush Switch 3. Brush Lift Lever 4. Vacuum Switch 5. Squeegee Lift Lever 6. Key Switch 7. Propel Buttons (Normally Forward) 8. Reverse Propel Button 9. Speed Control Knob 10. Battery Charge Level Indicator 11. - Page 15 CONTROLS - TRACTION 1. SOLUTION CONTROL KNOB Controls solution flow to scrub deck. To increase flow, rotate knob clockwise. To decrease flow, rotate knob counterclockwise. If the brush motor is turned off or the direction control lever is in neutral, the flow is automatically interrupted until the motor is turned on again.
-
Page 16: Controls
9. SPEED CONTROL KNOB Controls the speed of the machine. To increase speed, rotate knob clockwise. To decrease speed, rotate knob counterclockwise. 10. BATTERY CHARGE LEVEL INDICATOR Indicates the charge level of the batteries. The meter display is divided into 10 vertical bars. -
Page 17: Machine Operation
PRE-RUN MACHINE INSPECTION Do a pre-run inspection to find possible problems that could cause poor performance or lost time from breakdown. Follow the same procedure each time to avoid missing steps. NOTE: See maintenance section for pre-run machine inspection checklist items. STARTING MACHINE NOTE: Perform pre-run machine check before operating machine. -
Page 18: To Begin Scrubbing
MACHINE OPERATION TO BEGIN SCRUBBING CAUTION When operating the machine around people, pay close attention for unexpected movement. Use extra caution around children. WARNING Flammable liquids and/or reactive metals can cause explosions or fire! Do not pick up. 1. Turn the machine power on. 2. -
Page 19: Emptying & Cleaning Tanks
EMPTYING AND CLEANING TANKS 1. Park the machine next to a floor drain. Drain hoses are on the rear of the machine. 2. Turn the machine power off. SOLUTION TANK 1. Unhook the small drain hose from the retainer. Unscrew the T-handle plug enough to loosen it, then lower the hose in the direction of the drain. -
Page 20: Maintenance
MAINTENANCE BATTERIES The batteries provide the power to operate the machine. The batteries require regular maintenance to keep them operating at peak efficiency. The machine batteries will hold their charge for long periods of time, but they can only be charged a certain number of times. -
Page 21: Checking Battery Specific Gravity
CHECKING BATTERY SPECIFIC GRAVITY Use a hydrometer to check the battery specific gravity. Battery Check CHECKING GRAVITY A. Hydrometer B. Battery NOTE: Do not take readings immediately after adding distilled water, if the water and acid are not thoroughly mixed, the reading may not be accurate. -
Page 22: Changing Batteries
MAINTENANCE 4. Check the electrolyte level in each battery cell. Before charging, add just enough distilled water to cover the plates. After charging is complete, add just enough distilled water to bring up the level to the indicator ring. If the water level is too high before charging, normal expansion rate of the electrolyte may cause an overflow. -
Page 23: Types
SCRUB BRUSHES NOTE: All original equipment brushes are equipped with “Perform Alert©”. This feature will tell the operator when it is time to replace the scrub brush. “Perform Alert©” brushes have pre-trimmed bright yellow tufts to indicate the length of a worn out brush. - Page 24 MAINTENANCE SCRUB BRUSHES NOTE: All original equipment brushes are equipped with “Perform Alert©”. This feature will tell the operator when it is time to replace the scrub brush. “Perform Alert©” brushes have pre-trimmed bright yellow tufts to indicate the length of a worn out brush.
-
Page 25: Squeegee Blades
SQUEEGEE BLADES The front squeegee blade allows solution to pass through channels in the blade into the squeegee assembly while maintaining vacuum to provide lift. The rear blade wipes the floor to a near dry condition. It is important the rear blade be in good condition to properly do its job. -
Page 26: To Adjust Squeegee Pitch
MAINTENANCE TO ADJUST SQUEEGEE PITCH 1. Choose a smooth, level surface. Turn “ON” the key switch and vacuum switch. Lower the squeegee and drive forward at least 2 feet (60cm.). 2. With the squeegee down, stop the machine. Do not allow machine to roll back. FOR SAFETY: Before leaving or servicing the machine, stop on level surface, turn off machine and remove key. -
Page 27: Service Schedule
SERVICE SCHEDULE MAINTENANCE Check batteries after charging; add water if necessary Check pad wear to prevent buildup of chemicals Check linkages and connectors for wear and damage Check hoses for wear, blockages, or damage Clean squeegee; check for adjustment; inspect for wear Check handles, switches, knobs, domes, and gaskets for damage Clean out recovery tank... -
Page 28: Machine Troubleshooting
MACHINE TROUBLESHOOTING PROBLEM Poor or no water pick-up Vacuum motor does not run, or runs slowly Poor scrubbing performance Brush motor does not run, or runs slowly CAUSE Debris caught on squeegee Remove debris Worn squeegee blades Vacuum hose clogged Vacuum hose disconnected from squeegee or recovery tank... - Page 29 PROBLEM Little or no solution flow to the floor No power to machine Little or no propel (traction model only) MACHINE TROUBLESHOOTING CAUSE Solution tank empty Solution flow turned off or set too low Solution strainer plugged Solution hoses obstructed Solution solenoid valve obstructed or stuck (traction model only)
