  • Page 2 VSX-6101 VSX-6100 VSX-6100-EVB DM&P Vortex86SX 300MHz DIP48/68pin CPU Module with 3S/2USB/CF 128MB DDR2 Onboard User’s Manual (Revision 1.0A)
  • Page 3 No part of this manual may be reproduced, copied, translated or transmitted, in whole or in part, in any form or by any means without the prior written permission of the ICOP Technology Inc.. ©Copyright 2007 ICOP Technology Inc.

  • Page 4: Table Of Contents

    T a b l e C o n t e n t s T a b l e o f C o n t e n t s .............iii C h a p t e r 1 Introduction……………………………………………1 Packing List............1 Product Description ..........

  • Page 5: Chapter 1 Introduction

    C h a p t e r Introduction Packing List Product Name Package Embedded Vortex86SX DIP 48/ 68pin CPU VSX-6100-EVB Module EVB board x 1 Manual & Drivers CD x 1 Product Name Package Embedded Vortex86SX DIP 68Pin CPU Module RS232 cable x 3 USB cable x 1 VSX-6100...

  • Page 6: Product Description

    1.2 Product Description The VSX-6100/ 6101 family of low-power x86 embedded controller is designed to meet DIP 48/ 68pin CPU module specification, and integrated with the following features. 3 PWM channels 300 MHz Vortex86SX System-On-Chip 128MB DDR2 system memory JTAG interface 10/100Mbps Ethernet AMI BIOS 3 USB 2.0 (host)

  • Page 7: Specifications

    Specifications Features VSX-6100-EVB 2.00mm ∅10-pin header for RS-232 x1 Connectors 2.54mm ∅10-pin header for PWM x1 2.54mm ∅10-pin header for GPIO x3 2.54mm ∅ 3-pin header for SERVO x8 1.25mm ∅ 6-pin Wafer for JTAG x1 External USB connector x2 External RJ-45 connector for Ethernet x1 External 9-pin D-Sub male connector for RS-232 x1 Flash Disk Support...
  • Page 8 Features VSX-6100 DM&P SoC CPU Vortex86SX- 300MHz Real Time Clock with Lithium Battery Backup Cache L1:16K I-Cache, 16K D-Cache BIOS AMI BIOS System Memory 128MB DDR2 onboard Watchdog Timer Software programmable from 30.5 us to 512 seconds x2 sets(Watchdog 1 fully compatible with M6117D) I /O Interface RS-232 port x3 USB port x1 (USB 2.0 version)
  • Page 9 Features VSX-6101 DM&P SoC CPU Vortex86SX- 300MHz Real Time Clock with Lithium Battery Backup Cache L1:16K I-Cache, 16K D-Cache BIOS AMI BIOS System Memory 128MB DDR2 onboard Watchdog Timer Software programmable from 30.5 us to 512 seconds x2 sets(Watchdog 1 fully compatible with M6117D) I /O Interface RS-232 port x3 USB port x1 (USB 2.0 version)

  • Page 10: Board Dimension

    Board Dimension VSX-6100-EVB VSX-6100 /6101 Vortex86SX™ DIP 48/ 68pin CPU Module...
  • Page 11 VSX-6100 VSX-6100 /6101 Vortex86SX™ DIP 48/ 68pin CPU Module...
  • Page 12 VSX-6101 VSX-6100 /6101 Vortex86SX™ DIP 48/ 68pin CPU Module...

  • Page 13: Chapter 2 Installation

    C h a p t e r 2 Installation 2.1 Board Outline VSX-6100-EVB VSX-6100 /6101 Vortex86SX™ DIP 48/ 68pin CPU Module...
  • Page 14 VSX-6100 VSX-6100 /6101 Vortex86SX™ DIP 48/ 68pin CPU Module...
  • Page 15 VSX-6101 VSX-6100 /6101 Vortex86SX™ DIP 48/ 68pin CPU Module...

  • Page 16: Connectors & Jumpers Location

    Connectors & Jumpers Location VSX-6100-EVB VSX-6100 /6101 Vortex86SX™ DIP 48/ 68pin CPU Module...
  • Page 17 VSX-6100 VSX-6100 /6101 Vortex86SX™ DIP 48/ 68pin CPU Module...
  • Page 18 VSX-6101 VSX-6100 /6101 Vortex86SX™ DIP 48/ 68pin CPU Module...

  • Page 19: Connectors & Jumpers Summary

    Connectors & Jumpers Summary VSX-6100-EVB Summary Table Description Type of Connections nbrs. 10/100Base-T Ethernet LAN 8-pin RJ45 Connector GPIO Port 0 / 1 20-pin Pin Header, 2.54∅ ,10x2 USB 2 USB connector 4-pin Timer Counter COM2 20-pin Pin Header, 2.54∅ ,10x2 USB 1 USB connector 4-pin...
  • Page 20 VSX-6100 Summary Table Description Type of Connections nbrs. 5-pin Wafer, 1.25∅ , 5x1 PS/2 Keyboard 4-pin Wafer, 1.25∅ , 5x1 JTAG 6-pin Wafer, 1.25∅ , 6x1 COM3 3-pin Wafer, 1.25∅ , 3x1 COM4 3-pin Wafer, 1.25∅ , 3x1 Console Redirection 3-pin Slide Switch COM9...
  • Page 21 VSX-6101 Summary Table Description Type of Connections nbrs. USB 2 5-pin Wafer, 1.25∅ , 5x1 PS/2 Keyboard 4-pin Wafer, 1.25∅ , 5x1 JTAG 6-pin Wafer, 1.25∅ , 6x1 COM3 3-pin Wafer, 1.25∅ , 3x1 COM4 3-pin Wafer, 1.25∅ , 3x1 COM9 3-pin Wafer, 1.25∅...

  • Page 22: Pin Assignments & Jumper Settings

    2.4 Pin Assignments & Jumper Settings A: Pin Assignments & Jumper Settings of VSX-6100-EVB J2: GPIO (Port 0 / Port 1) Pin # Signal Name Pin # Signal Name GP00 GP10 GP01 GP11 GP02 GP12 GP03 GP13 GP04 GP14 GP05 GP15 GP06 GP16...
  • Page 23 J6: SERVO1 Pin # Signal Name J7:RS232 / TTL select (COM1) Pin # Signal Name OPEN COM1 RS232 CLOSE COM1 TTL / Port4 J8: SERVO2 Pin # Signal Name J9: SERVO3 Pin # Signal Name VSX-6100 /6101 Vortex86SX™ DIP 48/ 68pin CPU Module...
  • Page 24 J10: COM 1 Signal Signal Pin # Pin # Name Name DCD1 RXD1 TXD1 DTR1 DSR1 RTS1 CTS1 J11: SERVO4 Pin # Signal Name J12: System Power Connector (Terminal Block 5.0mm) Pin # Signal Name DC IN : 6V~24V J13: SERVO5 Pin # Signal Name J15: SERVO6...
  • Page 25 J16: SERVO7 Pin # Signal Name J17: SERVO Power Connector (Terminal Block 5.0mm) Pin # Signal Name J18: SERVO8 Pin # Signal Name J19: IRQ6 selection Pin # Signal Name IRQ6 VSX-6100 /6101 Vortex86SX™ DIP 48/ 68pin CPU Module...
  • Page 26 U1: DIP-68 Connector – 68pin Pin # Signal Name Pin # Signal Name PWRGND TXDEN2 GP00 CTS2\ GP01 DSR2\ GP02 DTR2\ GP03 RXD2\ GP04 GP05 RTS2 GP06 TXD2 GP07 DCD2\ SPICS/ GP30 SPICLIK/ GP31 46 GP23 SPIDO / GP32 GP24 SPIDI / GP33 GP25 GP34...
  • Page 27 B: Pin Assignments & Jumper Settings of VSX-6100 J2: USB Pin # Signal Name Pin # Signal Name LUSBD2- LUSBD2+ J3: PS/2 Keyboard Pin # Signal Name Pin # Signal Name KBCLK KBDAT J4: JTAG Pin # Signal Name Pin # Signal Name VSX-6100 /6101 Vortex86SX™...
  • Page 28 J5: COM3 Pin # Signal Name Pin # Signal Name TXD3 RXD3 J6: COM4 Pin # Signal Name Pin # Signal Name TXD4 RXD4 J7: COM9 Pin # Signal Name Pin # Signal Name TXD9 RXD9 J8: Slide Switch (Console Redirection) Pin # Signal Name Pin # Signal Name SPCIS...
  • Page 29 U5: DIP-68 Connector – 68pin Pin # Signal Name Pin # Signal Name PWRGND TXDEN2 GP00 CTS2\ GP01 DSR2\ GP02 DTR2\ GP03 RXD2\ GP04 GP05 RTS2 GP06 TXD2 GP07 DCD2\ SPICS/ GP30 SPICLIK/ GP31 GP23 SPIDO / GP32 GP24 SPIDI / GP33 GP25 GP34 GP26...
  • Page 30 C: Pin Assignments & Jumper Settings of VSX-6101 J2: USB Pin # Signal Name Pin # Signal Name LUSBD2- LUSBD2+ J3: PS/2 Keyboard Pin # Signal Name Pin # Signal Name KBCLK KBDAT J4: JTAG Pin # Signal Name Pin # Signal Name J5: COM3 Pin # Signal Name Pin # Signal Name...
  • Page 31 J6: COM4 Pin # Signal Name Pin # Signal Name TXD4 RXD4 J7: COM9 Pin # Signal Name Pin # Signal Name TXD9 RXD9 J8: Slide Switch (Console Redirection) Pin # Signal Name Pin # Signal Name SPCIS VSX-6100 /6101 Vortex86SX™...
  • Page 32 U5: DIP-48 Connector – 48pin Pin # Signal Name Pin # Signal Name PWRGND GP23 GP00 GP24 GP01 GP25 GP02 GP26 GP03 GP27 GP04 CTS1 / GP47 GP05 DSR1 / GP46 GP06 DTR1 / GP45 GP07 RXD1 / GP44 SPICS/ GP30 RI1 / GP43 SPICLIK/ GP31 RTS1 / GP42...

  • Page 33: System Mapping

    System Mapping VSX-6100 VSX-6100 /6101 Vortex86SX™ DIP 48/ 68pin CPU Module...
  • Page 34 VSX-6100 /6101 Vortex86SX™ DIP 48/ 68pin CPU Module...
  • Page 35 VSX-6100 /6101 Vortex86SX™ DIP 48/ 68pin CPU Module...
  • Page 36 VSX-6101 VSX-6100 /6101 Vortex86SX™ DIP 48/ 68pin CPU Module...
  • Page 37 VSX-6100 /6101 Vortex86SX™ DIP 48/ 68pin CPU Module...
  • Page 38 VSX-6100 /6101 Vortex86SX™ DIP 48/ 68pin CPU Module...

  • Page 39: Watchdog Timer

    Watchdog Timer There are two watchdog timers in Vortex86SX CPU. One is compatible with M6117D watchdog timer and the other is new. The M6117D compatible watchdog timer is called WDT0 and new one is called WDT1. We also provide DOS, Linux and WinCE example for your reference. For more technical support, please visit: http://www.dmp.com.tw/tech or download the PDF file:...

  • Page 40: Gpio

    GPIO (General Purpose Input / Output) 40 GPIO pins are provided by the Vortex86SX for general usage in the system. All GPIO pins are independent and can be configured as inputs or outputs, with or without pull-up/pull-down resistors. We also offer DOS, Linux and WinCE example for your reference. For more technical support, please visit: http://www.dmp.com.tw/tech or download the PDF file:...

  • Page 41: Spi Flash

    SPI flash (Serial Peripheral Interface) As SPI Flash (Serial Peripheral Interface) offers many benefits including: reduced controller pin count, smaller and simpler PCBs, reduced switching noise, less power consumption, and lower system cost Many of users may consider using a formatted SPI flash to boot for the system or emulate SPI flash as Floppy (A: Driver or B: Driver).

  • Page 42: Chapter 3 Driver Installation

    C h a p t e r Driver Installation The Vortex86SX processor also integrated 10/100Mbps Ethernet controller that supports both 10/100BASE-T and allows direct connection to your 10/100Mbps Ethernet based Local Area Network for full interaction with local servers, wide area networks such as the Internet. I/O and IRQ settings can be done by software with the supplied utility software, or it can be set for Plug and Play compatibility.

  • Page 43: Appendix

    Appendix A. TCP/IP library for DOS real mode DSock is a TCP/IP library for DOS real mode, which is used by RSIP. It provides simple C functions for programmer to write Internet applications. ICOP also provide Internet examples using DSock: BOOTP/DHCP, FTP server, SMTP client/server, HTTP server, TELNET server, Talk client/server, etc.

  • Page 44: Bios Default Setting

    B. BIOS Default setting If the system cannot be booted after BIOS changes are made, Please follow below procedures in order to restore the CMOS as default setting. Press “End” Key, when the power on Press <Del> to enter the AMI BIOS setup Press “F9”...

  • Page 45: Console Redirection Setting

    C. Console Redirection setting Hardware requirement: VSX-6100/ VSX-6101 & VSX-6100-EVB Any PC with COM port, which installed Windows XP ( or other Windows OS) with Hyper Terminal A D-Sub 9 pin Female to Female Cable. Enable the Console Redirection by hardware switch of VSX-6100 / VSX-6101. Enable the “Console Redirection”...
  • Page 46 VSX-6100 /6101 Vortex86SX™ DIP 48/ 68pin CPU Module...
  • Page 47 VSX-6100 /6101 Vortex86SX™ DIP 48/ 68pin CPU Module...
  • Page 48 VSX-6100 /6101 Vortex86SX™ DIP 48/ 68pin CPU Module...
  • Page 49 VSX-6100 /6101 Vortex86SX™ DIP 48/ 68pin CPU Module...

  • Page 50: Warranty

    Warranty This product is warranted to be in good working order for a period of one year from the date of purchase. Should this product fail to be in good working order at any time during this period, we will, at our option, replace or repair it at no additional charge except as set forth in the following terms.
