EVAL-M1-IM240-A User Manual
iMOTION™ Modular Application Design Kit
Main features of EVAL-M1-IM240-A
The module case temperature vs output power is shown as Figure 2. R
evaluation board and without fan cooling.
Figure 2
The module case temperature vs output power
User Manual
is based on the existing heatsink on the
th
R
@ 7 ℃/W
th
8
Revision 1.0
2020-07-10
