hardware
(H1) x 31
dowel
(H6) x 2
knob bolt
(H11) x 1
allen wrench
4
(H2) x 24
(H3) x 24
cam bolt
cam
(H7) x 32
(H8) x 16
short flat head screw
bolt
(H12) x 4
(H13) x 8
mounting plate
confirmat screw
(H4) x 23
(H5) x 2
short pan head screw
knob
(H9) x 16
(H10) x 18
lock washer
washer
(H14) x 1
(H15) x 1
wall anchor
wall screw
