Te c hn i cal Re fe re nce
020-102396-02
FHD492-XV and FHD552-XV
Serial Commands

Advertisement

Table of Contents
loading

Related Manuals for Christie FHD492-XV

Summary of Contents for Christie FHD492-XV

  • Page 1 Te c hn i cal Re fe re nce 020-102396-02 FHD492-XV and FHD552-XV Serial Commands...
  • Page 2 The warranty does not apply to any product where the serial number has been removed or obliterated. The warranty also does not apply to any product sold by a reseller to an end user outside of the country where the reseller is located unless (i) Christie has an office in the country where the end user is located or (ii) the required international warranty fee has been paid.

  • Page 3: Table Of Contents

    Content Communicating with the FHD492-XV or the FHD552-XV..... 5 Defining common terminology......... . . 5 Connection and use.
  • Page 4 Commands are not functioning as expected........31 FHD492-XV and FHD552-XV Serial Commands Technical Reference 020-102396-02 Rev. 1 (04-2017) Copyright 2017 Christie Digital Systems USA Inc. All rights reserved. ©...

  • Page 5: Communicating With The Fhd492-Xv Or The Fhd552-Xv

    HEX as a send format. For more information, see the Hercules SETUP utility help on the HW-Group website. FHD492-XV and FHD552-XV Serial Commands Technical Reference 020-102396-02 Rev. 1 (04-2017) Copyright 2017 Christie Digital Systems USA Inc. All rights reserved. ©...

  • Page 6: Sending Commands Using A Lan Connection

    1, 4, 6, 7, 8, 9 Input to the LCD display panel Output from the LCD display panel FHD492-XV and FHD552-XV Serial Commands Technical Reference 020-102396-02 Rev. 1 (04-2017) Copyright 2017 Christie Digital Systems USA Inc. All rights reserved. ©...
  • Page 7 Depending on the command, data fields may be left empty. Checksum • Checksum range: 0 to 255 (0xFF) FHD492-XV and FHD552-XV Serial Commands Technical Reference 020-102396-02 Rev. 1 (04-2017) Copyright 2017 Christie Digital Systems USA Inc. All rights reserved. ©...
  • Page 8 • Checksum algorithm: The EXCLUSIVE-OR (XOR) of all bytes in the message from the Header byte to the last Data byte. The Checksum itself is not included in this calculation. Christie recommends using a checksum calculator to perform this calculation.

  • Page 9: Command Code Summary

    Color temperature 0x35 This command requests that a display panel report its current color temperature FHD492-XV and FHD552-XV Serial Commands Technical Reference 020-102396-02 Rev. 1 (04-2017) Copyright 2017 Christie Digital Systems USA Inc. All rights reserved. ©...
  • Page 10 Auto signal detecting 0xAE This command sends a request to change the Auto Signal Detecting setting on a display panel FHD492-XV and FHD552-XV Serial Commands Technical Reference 020-102396-02 Rev. 1 (04-2017) Copyright 2017 Christie Digital Systems USA Inc. All rights reserved. ©...
  • Page 11 IR remote control 0xFD This command requests that the IR remote control send the IR key to a display panel FHD492-XV and FHD552-XV Serial Commands Technical Reference 020-102396-02 Rev. 1 (04-2017) Copyright 2017 Christie Digital Systems USA Inc. All rights reserved. ©...

  • Page 12: Constructing The Command Message

    0x19 DATA[1] 0x01 = Power Off 0x02 = Power On Examples Report the power state (power is off): FHD492-XV and FHD552-XV Serial Commands Technical Reference 020-102396-02 Rev. 1 (04-2017) Copyright 2017 Christie Digital Systems USA Inc. All rights reserved. ©...

  • Page 13: Power State: Set Command

    Code Code Length Data Data[0] Data[1] Checksum Control 0xA6 0x01 0x00 0x00 0x00 0x04 0x01 0x18 0x02 0xB8 FHD492-XV and FHD552-XV Serial Commands Technical Reference 020-102396-02 Rev. 1 (04-2017) Copyright 2017 Christie Digital Systems USA Inc. All rights reserved. ©...

  • Page 14: Sending General Messages

    Bytes Values DATA[0] 0x1D REPORT DATA[0] 0x1D DATA[1] 0x00 = lock the remote control and local keyboard function FHD492-XV and FHD552-XV Serial Commands Technical Reference 020-102396-02 Rev. 1 (04-2017) Copyright 2017 Christie Digital Systems USA Inc. All rights reserved. ©...

  • Page 15: Sending Cold Start Power State Commands

    0x02 = Last Status DATA[0] 0xA3 DATA[1] 0x00 = Power Off 0x01 = Forced On 0x02 = Last Status FHD492-XV and FHD552-XV Serial Commands Technical Reference 020-102396-02 Rev. 1 (04-2017) Copyright 2017 Christie Digital Systems USA Inc. All rights reserved. ©...

  • Page 16: Sending Input Source Messages

    • 0x06 = COMPONENT • 0x08 = VGA • 0x09 = HDMI2 • 0x0A = HDMI • 0x0B = DVI-D FHD492-XV and FHD552-XV Serial Commands Technical Reference 020-102396-02 Rev. 1 (04-2017) Copyright 2017 Christie Digital Systems USA Inc. All rights reserved. ©...
  • Page 17 Unit: 100ms Example: Switch to DVI-D with no delay Field Value Header 0xA6 Monitor ID 0x01 Category 0x00 FHD492-XV and FHD552-XV Serial Commands Technical Reference 020-102396-02 Rev. 1 (04-2017) Copyright 2017 Christie Digital Systems USA Inc. All rights reserved. ©...

  • Page 18: Sending Auto Signal Detecting Status Commands

    Learn how to obtain and change the Auto Signal Detecting status. Commands Type Bytes Values DATA[0] 0xAF REPORT DATA[0] 0xAF DATA[1] 0x00 = Off 0x01 = On FHD492-XV and FHD552-XV Serial Commands Technical Reference 020-102396-02 Rev. 1 (04-2017) Copyright 2017 Christie Digital Systems USA Inc. All rights reserved. ©...
  • Page 19 Sending input source messages Type Bytes Values DATA[0] 0xAE DATA[1] 0x00 = Off 0x01 = On FHD492-XV and FHD552-XV Serial Commands Technical Reference 020-102396-02 Rev. 1 (04-2017) Copyright 2017 Christie Digital Systems USA Inc. All rights reserved. ©...

  • Page 20: Sending Video Messages

    Contrast = 0 to 100 of the user- selectable range DATA[4] Sharpness = 0 to 20 (0x0 ~ 0x14) of the user-selectable range FHD492-XV and FHD552-XV Serial Commands Technical Reference 020-102396-02 Rev. 1 (04-2017) Copyright 2017 Christie Digital Systems USA Inc. All rights reserved. ©...

  • Page 21: Sending Picture Format Commands

    Learn the commands for getting or setting the color temperature. Commands Type Bytes Values DATA[0] 0x35 REPORT DATA[0] 0x35 DATA[1] 0x00 = Custom FHD492-XV and FHD552-XV Serial Commands Technical Reference 020-102396-02 Rev. 1 (04-2017) Copyright 2017 Christie Digital Systems USA Inc. All rights reserved. ©...

  • Page 22: Sending Color Temperature Parameters Commands

    Green Color Gain Value = 0 to 255 of the user-selectable range DATA[3] Blue Color Gain Value = 0 to 255 of the user-selectable range FHD492-XV and FHD552-XV Serial Commands Technical Reference 020-102396-02 Rev. 1 (04-2017) Copyright 2017 Christie Digital Systems USA Inc. All rights reserved. ©...

  • Page 23: Sending Audio Messages

    • Note that the three values must conform to the following rule: • Min <= Switch On <= Max FHD492-XV and FHD552-XV Serial Commands Technical Reference 020-102396-02 Rev. 1 (04-2017) Copyright 2017 Christie Digital Systems USA Inc. All rights reserved. ©...

  • Page 24: Sending Audio Parameters Commands

    Treble = -8 to 8 (0x2A ~0x3A) of the user-selectable range DATA[2] Bass = -8 to 8 (0x2A ~ 0x3A) Of the user-selectable range FHD492-XV and FHD552-XV Serial Commands Technical Reference 020-102396-02 Rev. 1 (04-2017) Copyright 2017 Christie Digital Systems USA Inc. All rights reserved. ©...

  • Page 25: Sending Other Messages

    0x02 = operating hours (all other values are reserved) REPORT DATA[0] 0x0F DATA[1] 0x00 DATA[2] 0x01 = Signal loss 0x02 = Signal stable FHD492-XV and FHD552-XV Serial Commands Technical Reference 020-102396-02 Rev. 1 (04-2017) Copyright 2017 Christie Digital Systems USA Inc. All rights reserved. ©...

  • Page 26: Sending Auto Adjust Setting Commands

    Type Bytes Values DATA[0] 0x2F REPORT DATA[0] 0x2F DATA[1] Temperature sensor 1 = 0-100°C, reported in hex values FHD492-XV and FHD552-XV Serial Commands Technical Reference 020-102396-02 Rev. 1 (04-2017) Copyright 2017 Christie Digital Systems USA Inc. All rights reserved. ©...

  • Page 27: Sending Tiling Commands

    Figure 2—The hexadecimal position values in a 5x5 array. Commands Type Bytes Values DATA[0] 0x23 REPORT DATA[0] 0x23 DATA[1] 0x00 = Do not enable FHD492-XV and FHD552-XV Serial Commands Technical Reference 020-102396-02 Rev. 1 (04-2017) Copyright 2017 Christie Digital Systems USA Inc. All rights reserved. ©...

  • Page 28: Sending Blacklight Level Commands

    DATA[0] 0x31 REPORT DATA[0] 0x31 DATA[1] Backlight value = 0 to 100 of the user-selectable range DATA[0] 0x30 FHD492-XV and FHD552-XV Serial Commands Technical Reference 020-102396-02 Rev. 1 (04-2017) Copyright 2017 Christie Digital Systems USA Inc. All rights reserved. ©...

  • Page 29: Sending A Factory Reset Command

    0xC1 = Red 0xC2 = Green 0xC3 = Yellow 0xC4 = Blue 0xD1 = Format 0xD2 = Info FHD492-XV and FHD552-XV Serial Commands Technical Reference 020-102396-02 Rev. 1 (04-2017) Copyright 2017 Christie Digital Systems USA Inc. All rights reserved. ©...
  • Page 30 0x05 = Button 5 0x06 = Button 6 0x07 = Button 7 0x08 = Button 8 0x09 = Button 9 FHD492-XV and FHD552-XV Serial Commands Technical Reference 020-102396-02 Rev. 1 (04-2017) Copyright 2017 Christie Digital Systems USA Inc. All rights reserved. ©...

  • Page 31: Troubleshooting

    Understanding the command format (on page 6). • Verify that all values are written in hexadecimal notation. FHD492-XV and FHD552-XV Serial Commands Technical Reference 020-102396-02 Rev. 1 (04-2017) Copyright 2017 Christie Digital Systems USA Inc. All rights reserved. ©...
  • Page 32 Corporate offi ces Worldwide offi ces USA – Cypress Australia Eastern Europe and India Singapore ph: 714-236-8610 ph: +61 (0) 7 3624 4888 Russian Federation ph: +91 (080) 6708 9999 ph: +65 6877-8737 ph: +36 (0) 1 47 48 100 Canada –...
