Summary of Contents for Christie FHD492-XV

  • Page 2     이 기기는 업무용 급 으로 전자파적합등록을 한 기기이오니 판매자 또는 사용자는 이점을 주의하시기 바라며 가정 외의 지역에서 사용하는 것을 목적으로 합니다...
  • Page 3 Connecting multiple displays in a daisy-chain ................. 19 Display control connection ....................19 Digital video connection for DVI ..................20 Digital video connection for DisplayPort ................20 Analog video connection ....................20 HDMI video connection ..................... 21 FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)
  • Page 4 VGA resolution ........................34 SDTV resolution ........................34 HDTV resolution ........................35 UHDTV resolution ........................ 35 Mura ..........................35 How to spot Mura ......................35 How to avoid Mura ......................36 FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)
  • Page 5 Some picture elements do not light up ................... 40 After-images are still seen on display when it is off ..............40 Display ..........................41 In/Out terminals ......................... 41 General ..........................42 Environmental conditions ..................... 42 Internal speaker ......................... 43 FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)
  • Page 6 Remove the foreign substance or water and send the unit to the maintenance center.  Do not store or use the display in locations exposed to heat, direct sunlight, or extreme cold. FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)
  • Page 7 LCD panel technology. In most cases, the burned in image will disappear gradually over a period of time after the power has been switched off. Severe burn-in symptoms will not disappear and cannot be repaired. This is not covered under the terms of your warranty. FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)
  • Page 8 Please find out about the local regulations on how to dispose of your old display from your local dealer. (For customers in Canada and U.S.A.) FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)
  • Page 9 End of Life Directives-Recycling Your new Public Information Display contains several materials that can be recycled for new users. Please dispose of according to all Local, State, and Federal laws. FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)

  • Page 10: Unpacking

    The product can normally operate only under 3000m in altitude. In installations at altitudes above 3000m, some abnormalities may be experienced. FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)

  • Page 11: Remote Control

    1. Lay a protective sheet on a table beneath the screen surface so as not to scratch the screen face. 2. Ensure you have all accessories for mounting this display. 3. Follow the instructions that come with the base mounting kit. FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)
  • Page 12 While facing the back of the panel, rotate it 90 degrees counterclockwise. Mount the display. To install an OPS device on the display: Remove the screws on the OPS cover. Install the OPS device. Fix the OPS device by screws. FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)
  • Page 13 Indicates the operating status of the display without - (Minus) button the OPS: While the OSD menu is on, decreases the adjustment.  Green—the display is turned on While the OSD menu is off, decreases the audio FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)
  • Page 14 Audio input for VGA source (3.5 mm stereo phone). function. SPEAKER SWITCH LAN control function for the use of the remote Internal speaker on/off switch. control signal from the control center. FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)

  • Page 15: Identifying A Remote Control

    Enter text for a network setting, or press to set the display ID. See Identifying a remote control for details. FORMAT button VOLUME buttons Change the aspect ratio of the Increase or decrease the audio FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)
  • Page 16 1. Press and slide the cover to open it. 2. Align the batteries according to the (+) and (–) indicators inside the battery compartment. 3. Replace the cover. When handling the remote:  Do not subject to strong shock. FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)
  • Page 17 Do not allow water or other liquid to splash the remote control. If the remote control gets wet, wipe it dry immediately. • Avoid exposure to heat and steam. • Other than to install the batteries, do not open the remote control. FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)
  • Page 18 2. Point the top of the remote control toward the IR Sensor cable when pressing a button. NOTE: The display’s remote control sensor stops working after connected with the IR Sensor cable. FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)
  • Page 19 Connect multiple displays to create a daisy-chain configuration for applications such as a video wall. For larger video wall configurations, Christie recommends using a distribution amp. A maximum of 100 display panels (10 x 10) can be used in a daisy-chain configuration.
  • Page 20 Connect the DP OUT connector of DISPLAY 1 to the DP IN connector of DISPLAY Connect the DVI OUT / VGA OUT connector of DISPLAY 1 to the VGA IN connector of DISPLAY 2. FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)
  • Page 21 Note that the first panel in the daisy-chain configuration must have the HDMI signal switched to a DVI signal. Connect the DVI OUT connector of DISPLAY 1 to the DVI IN connector of DISPLAY 2. FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)
  • Page 22 Connecting external equipment FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)

  • Page 23: Picture Menu

    2. Press Left or Right and select Picture style. 3. Press OK. 4. To choose your settings, press Up or Down, and select one of the following options:  Personal—Apply your personalized settings.  Vivid—Ideal for daytime viewing. FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)
  • Page 24 Appropriate settings on your computer firewall that allow you to run the media server.  It is recommended that you have a LAN cable connecting your display to your home network. 1. Connect the display and the computer to the same home network. FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)
  • Page 25 10. Navigate to the directory where you saved your media files. Right click a file, and select Play To. 11. Choose a display, and then click the file to play the content. FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)
  • Page 26 To pause a track, press OK. To resume playback, press OK again.  To rewind or fast forward a track, press Rewind or Fast Forward. To toggle between different speeds, press either button again.  To stop the music, press Stop. FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)
  • Page 27 1. In the top bar at the top of the display, select Photo. 2. Select a photo thumbnail, and then press OK. 1. Open a folder that contains multiple photos, and select a photo. FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)
  • Page 28  Colour Enhancement— Enhance the vividness and details of colors. ADVANCED Access advanced settings.  Gamma—Adjust the non- linear setting for picture luminance and contrast. FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)

  • Page 29: Menu Item Description

    Use the tiling menu options if you are building an array of display panels. You can create arrays that contain up to 100 display panels, up to 10 vertically and 10 horizontally. FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)

  • Page 30: Menu Item

    To disable the lock function, on the remote function. control, press Home, and then press 1998.  Lock All—Lock all keyboard functions.  Lock but Volume—Disable all keyboard functions except for FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)
  • Page 31 ID number. When APM is turned on, the display — automatically turns off if a signal is unavailable. INFORMATION By default, when a display is turned on from — FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)
  • Page 32 Each playlist can support up to 30 files. Playlists are not cleared if you restore factory settings. Files must be manually removed or deleted using the usb_schedulinglist.txt file on the USB. Menu item Description Options FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)
  • Page 33 NETWORK NAME If you are working with an array of — display panels, you can rename each display using the on-screen keyboard or the remote control keypad. FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)
  • Page 34 Aspect Ratio Stand for Mode H Pixels V Lines 480i 29.97 Hz 13.5 MHz Modified NTSC Standard 480p 59.94 Hz 27 MHz 576i 25 Hz 13.5 MHz Modified PAL Standard 576p 50 Hz 27 MHz FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)

  • Page 35: Mura

    Impurities or foreign particles in the crystal matrix  Uneven distribution of LCD matrix during manufacturing  Non-uniform luminance distribution of the backlight  Panel assembly induced stress  Flaws within the LCD cells FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)

  • Page 36: Display

    Input mode  Thermal induced stress—high temperature operation over long periods of time Although Christie can not guarantee the complete eradication of Mura every time, the appearance of Mura can be minimized by these methods:  Lower the backlight brightness ...
  • Page 37 Do not use volatile substances such as insert sprays, solvents, and thinners on the cabinet.  Do not place anything made from rubber or PVC near the cabinet for any extended periods of time. FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)
  • Page 38 Move the display to another location to see if the interference or noise is reduced. Color on the display is abnormal. This issue is caused if the signal cable is not connected properly. FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)
  • Page 39 I can hear sound but I cannot see a picture on the display. Most likely this means an improperly connected source signal cable. Make sure both video inputs and sound inputs are correctly connected. FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)
  • Page 40 Do not allow a still picture to be displayed for an extended period of time as this can cause a permanent after- image to remain on the display. To minimalize still pictures, Christie recommends enabling the screen saver mode on your devices.
  • Page 41 HDMI jack x 2 (type A) Digital RGB: TMDS (video and audio) (18 pin) Maximum: HDMI input Video—720p, 1080p, 1920 x 1080/60 Hz Audio—48 KHz/ 2 Channel (L+R) Supports LPCM only FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)

  • Page 42: Environmental Conditions

    (@handle)/56.8 (@wall mount) 71.1(@handle)/56.8(@wall mount) mm Weight 19 kg 24.7 kg Gross weight 24.9 kg 31.1 kg Learn about the environmental conditions. Item FHD492-XV and FHD552-XV Operational Temperature 0 to 40°C FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)

  • Page 43: Internal Speaker

    Learn about the internal speaker specifications. Item FHD492-XV and FHD552-XV Type 1 way 1 speaker Input 10 W (RMS) Impedance 8Ω Output sound pressure 82 dB/W/M Frequency response 160 Hz to 13 KHz FHD492-XV and FHD552-XV User Manual 020-001139-01 Rev. 1 (08-2016)
