2562427A REV. A 409
Safety Message to Installers and Service Personnel of Warning Light
Equipment
People's lives depend on your proper installation and servicing of Federal Signal products. It is
important to read and follow all instructions shipped with this product. In addition, listed below
are some other important safety instructions and precautions you should follow:
Before Installation or Service
Qualifications
To properly install or service this equipment, you must have a good understanding of automotive
mechanical and electrical procedures and systems, along with proficiency in the installation and
service of safety warning equipment. Always refer to the vehicle's service manuals when performing
equipment installations on a vehicle.
Light Hazards
To be an effective warning device, this product produces bright light that can be hazardous to your
eyesight when viewed at a close range. Do not stare directly into this lighting product at a close
range or permanent damage to your eyesight may occur.
Do not install the light system in an area that would block, impair or blind the driver's vision. Ensure
that the light system is mounted in a position that is outside of the driver's field of vision, so the driver
can safely operate the vehicle.
Federal Signal power supplies and light heads are designed to work together as a system. Com-
bining light heads and a power supply from different manufacturers may reduce the warning ef-
fectiveness of the lighting system and may damage the components. You should verify or test your
combination to ensure the system works together and meets federal, state and local standards or
guidelines.
Electrical Hazards
Strobe systems present a shock hazard because they use high voltage to operate. Do not handle
strobe cables, the power supply or bulbs or remove the lens while the equipment is connected.
Strobe systems can also hold their charge even after they have been turned off. After disconnecting
power to the unit, wait five minutes before handling any parts of the strobe system.
A light system is a high current system. For the system to function properly, a separate negative
(–) connection and positive (+) connection must be made. All negative connections should be con-
nected to the negative battery terminal and a suitable fuse should be installed on the positive battery
terminal connection as close to the battery as possible. Ensure that all wires and fuses are rated
correctly to handle the device and system amperage requirements.
Never attempt to install aftermarket equipment that connects to the vehicle wiring without reviewing
a vehicle wiring diagram available from the vehicle manufacturer. Ensure that your installation will not
affect vehicle operation or mandated safety functions or circuits. Always check the vehicle for proper
operation after installation.
Installation and Service Instructions for
Q
F
™ Halogen Scene Light
uadra
lare
Model QL97HSCENE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QuadraFlare QL97HSCENE and is the answer not in the manual?

Questions and answers

Summary of Contents for Federal Signal Corporation QuadraFlare QL97HSCENE

  • Page 1 Installation and Service Instructions for ™ Halogen Scene Light uadra lare Model QL97HSCENE 2562427A REV. A 409 Safety Message to Installers and Service Personnel of Warning Light Equipment People’s lives depend on your proper installation and servicing of Federal Signal products. It is important to read and follow all instructions shipped with this product.
  • Page 2 Halogen Scene Light Model QL97HSCENE uadra lare • The lighting system components, especially light bulbs, strobe tubes, LEDs, and the outer housing, get hot during operation. Be sure to disconnect power to the system and allow the system to cool down before handling any components of the system.
  • Page 3: Product Overview

    Halogen Scene Light Model QL97HSCENE uadra lare After Installation or Service • After installation, test the light system to ensure that it is operating properly. Test all vehicle functions, including horn operation, vehicle safety functions and vehicle light systems, to ensure proper operation. Ensure that the installation has not affected the vehicle operation or changed any vehicle safety func- tion or circuit.
  • Page 4 Halogen Scene Light Model QL97HSCENE uadra lare Mounting and Wiring the Model QL97HSCENE AIRBAG DEPLOYMENT Do not install equipment or route wiring in the deployment path of an airbag. Failure to observe this warning will reduce the effectiveness of the airbag or potentially dislodge the equipment, causing serious injury to you or others.
  • Page 5: Testing The Installation

    Plexus seals the pores of the plastic, making the plastic easier to clean, improving scratch resistance, and increasing product longevity. Plexus is available in cases of twelve 13 oz aerosol cans (PX13) from Federal Signal Corporation, Emer- gency Products.
  • Page 6: Getting Technical Support

    Test the vehicle only in a controlled environment. Getting Technical Support For technical support, please contact: Service Department Federal Signal Corporation Phone: 1-800-433-9132 Fax: 1-800-343-9706 Email: empserviceinfo@fedsig.com...
  • Page 7: Ordering Replacement Parts

    Halogen Scene Light Model QL97HSCENE uadra lare Ordering Replacement Parts To order replacement parts (Table 2), please contact your local dealer/distributor or: Mobile Systems Customer Support Federal Signal Corporation Phone: 1-800-264-3578 Table 2: Replacement parts Description Part Number Lamp, Halogen...
  • Page 8 Halogen Scene Light Model QL97HSCENE uadra lare 7.40" 7.25" 5.60" 3.70" 0.25" DIAMETER 3.625" (4 PLACES) 2.80" 3.25" CUT OUT THIS AREA 2.625" FOR REFLECTOR CLEARANCE 1.75" 3.50" 5.25" 6.50" 256A6238 Figure 1: Dimensions of mounting surface SCREW GROMMET T I N MOUNTING GASKET SHEET METAL AREA TO BE CUT OUT...
  • Page 9 Halogen Scene Light Model QL97HSCENE uadra lare SCREW GROMMET T I N SHEET METAL AREA TO BE CUT OUT FOR REFLECTOR CLEARANCE OPTIONAL TRIM RING BASE SCREW M 4.2 x 38 (4) TRIM RING GASKET LAMP INNER GASKET LENS (NOTE THE ORIENTATION: THE WORD “TOP”...
  • Page 10 2645 Federal Signal Drive, University Park, IL 60466-3195 Tel.: (800) 264-3578 • Fax: (800) 682-8022 www.fedsig.com is a trademark of Federal Signal Corporation. uadra lare © 2009 Federal Signal Corporation...
