Summary of Contents for Federal Signal Corporation QuadraFlare QL64Z3V-LI
- Page 1 ™ uadra lare Models QL64Z3V-LI and QL64Z3V-RI Installation Manual 2562429B REV. B 1109 Printed in U.S.A.
-
Page 2: Table Of Contents
Contents Safety Message to Installers and Service Personnel ......1 Safety Message to Operators of Warning Light Equipment ....4 Product Overview .................. 6 Unpacking the Product ................6 Mounting the Q Lights ............6 uadra lare Making Electrical Connections ............. 7 Completing the Installation .............. -
Page 3: Safety Message To Installers And Service Personnel
Safety Message to Installers and Service Personnel of Warning Light Equipment People’s lives depend on your proper installation and servicing of Fed- eral Signal products. It is important to read and follow all instructions shipped with this product. In addition, listed below are some other im- portant safety instructions and precautions you should follow: Before Installation or Service Qualifications... - Page 4 Warning Lights uadra lare • A light system is a high current system. For the system to function properly, a separate negative (–) connection and positive (+) connec- tion must be made. All negative connections should be connected to the negative battery terminal and a suitable fuse should be installed on the positive battery terminal connection as close to the battery as possible.
- Page 5 Warning Lights uadra lare • If a vehicle seat is temporarily removed, verify with the vehicle manu- facturer if the seat needs to be recalibrated for proper airbag deploy- ment. • Before mounting any components, check the manual to be sure that the component you are installing is suitable for use in that area of the vehicle.
-
Page 6: Safety Message To Operators Of Warning Light Equipment
Warning Lights uadra lare that the installation has not affected the vehicle operation or changed any vehicle safety function or circuit. • Scratched or dull reflectors, mirrors or lenses will reduce the effective- ness of the lighting system. Avoid heavy pressure and use of caustic or petroleum based products when cleaning the lighting system. - Page 7 Warning Lights uadra lare • To be an effective warning device, this product produces bright light that can be hazardous to your eyesight when viewed at a close range. Do not stare directly into this lighting product at a close range or per- manent damage to your eyesight may occur.
-
Page 8: Product Overview
Warning Lights uadra lare Product Overview Models QL64Z3V-L1 and QL64Z3V-R1 are three-head Q light uadra lare assemblies designed to operate on 12 Vdc. They are intended for mounting on the rear exterior of a vehicle. Both models have a BTT (Brake, Turn, Tail), TURN or ARROW, and BACKUP Q light assembly. -
Page 9: Making Electrical Connections
Warning Lights uadra lare LOCATING OPERATOR CONTROLS Locate the light system controls so the VEHICLE and CONTROLS can be operates safely under all driving conditions. Failure to heed this warning could result in driver distraction or driver error while operating the vehicle. Before proceeding with the installation, determine the approximate location of the light assembly and plan all mating connections. -
Page 10: Completing The Installation
NOTE : The most effective product you can use for cleaning, protecting, and polishing clear and colored plastics is Plexus. Plexus is available in cases of 12 aerosol cans from Federal Signal Corporation, Emergency Products, in either 7-ounce cans (PX7) or 13-ounce cans (PX13). Over time, exposure to heat, sunlight, and smog causes plastic to fade, discolor, scratch, or become brittle. - Page 11 Warning Lights uadra lare 4.50" 14.38" Ø1.50" (3 PLACES) Ø.21" (4 PLACES) VEHICLE MOUNTING BODY GASKET #10 X 3/4" SCREW(4) 3.0" VEHICLE BODY MOUNTING #10 X 3/4" GASKET SCREW(4) 290A6150 Figure 1: Vertical and horizontal mounting...
-
Page 12: Getting Service And Parts
Distributor or Manufacturer’s Representative. Please provide a brief explanation of the service requested or the nature of the malfunction. Address all communications and shipments to: Service Department Federal Signal Corporation Phone: 1-800-433-9132 Fax: 1-800-343-9706 Email: empserviceinfo@fedsig.com to 5... - Page 13 2645 Federal Signal Drive, University Park, IL 60484-3167 Tel.: (800) 264-3578 • Fax: (800) 682-8022 © 2009 Federal Signal Corporation www.fedsig.com...
