Sun Oracle Netra SPARC T5-1B Installation Manual page 39

8N1 (eight data bits, no parity, one stop bit)
■
9600 baud (the default, but can be set to any standard rate up to 57600)
■
Disable hardware flow control (CTS/RTS)
■
2. Connect the dongle cable to the UCP connector on the front panel of the server
module.
If possible, use a three-connector UCP-3 dongle cable rather than a four-connector
UCP-4. See "Dongle Cables" on page 17
3. Connect a terminal or terminal emulator to the dongle cable.
For a UCP-3 dongle cable, use the RJ-45 connector.
■
For a UCP-4 dongle cable, use the DB-9 serial connector (TTYA). If you need to
■
make an RJ-45 connection to a UCP-4, do so through a DB-9-to-RJ-45 adapter
attached to the DB-9 connector.
The Oracle ILOM login prompt is displayed on the terminal or terminal emulator.
4. Type the user name and password when prompted.
The default user is root. The default password is changeme.
Note – To enable first-time login and access to Oracle ILOM, a default Administrator
account and its password are provided with the system. To build a secure
environment, you must change the default password (changeme) for the default
Administrator account (root) after your initial login to Oracle ILOM. If this default
Administrator account has been changed, contact your system administrator for an
Oracle ILOM user account with Administrator privileges.
Refer to the Oracle ILOM documentation for information on changing passwords.
You are now logged into Oracle ILOM on the server module SP.
5. If you do not plan to use the preinstalled OS, do not perform the remaining
steps.
Instead, go to "Reach a State to Install a Fresh OS (Oracle ILOM CLI)" on page
6. Power on the host.
-> start /System
Are you sure you want to start /System (y/n)? y
Starting /System. . .
The server module initializes.
for details.
Powering On the Server Module for the First Time
43.
33
