Insert The Server Module Into The Chassis - Sun Oracle Netra SPARC T5-1B Installation Manual

Related Information
"Prepare the Modular System and Server Module" on page 21
■
"Install Optional Components" on page 22
■
▼ Insert the Server Module Into the
Chassis
There are limitations on the total number of server modules that you can install in a
modular system. Refer to the Netra SPARC T5-1B Server Module Product Notes,
configuring server module power usage for details.
1. If you have not done so, prepare the modular system and server module.
See "Prepare the Modular System and Server Module" on page
2. If you have not done so, install any optional components.
See "Install Optional Components" on page
3. Remove the protective cover from the rear connector of the server module.
4. Be prepared to communicate with the server module after completing the
physical installation.
As soon as you insert the server module in a powered modular system, power is
supplied to the server module and the SP generates messages. If you want to see
these messages, be ready to connect using one of the methods in
Communication With the Server Module During Installation" on page
5. Locate the slot in the chassis where you plan to install the server module.
A filler panel should remain in this slot until just before you are ready to insert the
server module. All slots should remain filled with server modules or filler panels
to ensure correct air flow, heat, and electromagnetic interference conditions in the
modular system.
6. Remove the filler panel from the selected chassis slot.
Pull down the ejector arm of the filler panel, then pull the panel straight out of the
chassis.
Caution – Be ready to insert the server module within 60 seconds of removing the
filler panel.
21.
22.
"Plan
Installing the Server Module
15.
23
