Swivel and Slide Operation

Do not attempt to operate the Swivel Seat Base while the vehicle is motion.
The seat slide lever that operates the Swivel Slide Seat Base is on the right side (curbside) of the driver seat
and on the left side (roadside) of the passenger seat.
1.
Pull the seat slide lever up (Fig. 1) to slide the seat base from its original position towards the center of
the vehicle at a 45 degree angle (Fig. 2).
NOTE: Driver side seat base shown.
Roadside
2.
After the slide mechanism has clicked into place, the seat can be rotated up to 180 degrees from the
forward-facing position.

Drive Position

Swivel seat base must be locked into the foward-facing position before putting vehicle into motion.
To return to a driving position:
1. Swivel the seat back to the forward-facing position.
2.
Pull up on the seat side lever (Fig. 1) and slide the seat back to the drive position until it clicks into place.

Maintenance

There are no servicable parts in the Sliding Swivel Seat Base.
Rev: 05.09.19
Fig. 1
Front
Curbside
Seat Slide
Lever
Rear Seat Base Out at 45 Degree Angle
Page 3
Fig. 2
CCD-0001601
