System Information; Safety - Lippert Components Sliding Swivel Seat Base Owner's Manual

System Information

Safety

Swivel and Slide Operation
Drive Position
Maintenance
System Information
The Sliding Swivel Seat Base allows the user to slide the seat base out at a 45° angle, so that the seat can be
swiveled 180°. There are five models of the seat base available for the vehicles listed below.
NOTE: There are slight differences in appearance between the different models, but they all function the
same as the model shown.
Safety
This manual provides general instructions. Many variables can change the circumstances of the intended
instructions, i.e. the degree of difficulty involved in the service operation and the ability of the individual
performing the operation. This manual cannot begin to plot out instructions for every possibility, but will
provide the general instructions, as necessary, for operating and servicing the device, product or system.
In the event the skill level required is too advanced or the procedure too difficult, a certified technician
should be consulted before performing the necessary service. Failure to correctly perform a troubleshooting
procedure may result in voiding the warranty, inflicting personal injury or death.
The "WARNING" symbol above is a sign that a procedure has a safety risk involved and may cause death
or serious personal injury if not performed safely and within the parameters set forth in this manual.
Failure to follow instructions provided in this manual may result in death, serious personal injury
and/or severe product and property damage, including voiding of the component warranty.
The "CAUTION" symbol above is a sign that a procedure has a safety risk involved that may cause
personal injury and/or product damage, including voiding of warranty, if not performed safely and
Rev: 05.09.19
TABLE OF CONTENTS
Part Number
696038
696039
670698
670699
in accordance with the safety procedures stated herein.
Moving parts can pinch, crush or cut. Keep clear and use caution.
Vehicles and Seat
Ford CLS C (Driver Side)
Ford CLS C (Passenger Side)
Freightliner (Driver Side)
Freightliner (Passenger Side)
Page 2
2
2
3
3
3
CCD-0001601
