1.6 Transducer Accessories

ACCESSORY
Velocity
Transducer
Housing
Assembly
Quick Connect
Semi-permanent
mounting method
using permanently
mounted bolts.
Several bolts can
be mounted and a
single velocity
transducer carried
from bolt to bolt to
measure vibration.
Super Mag 100
Quick temporary
method for
mounting a
velocity
transducer.
Junction Boxes
Weather proof or explosion proof housing for making
electrical connections to interconnect cables.
Flexible Conduit 1/2 in. (1.27 cm)
3/4 in. (1.91 cm)
A convenient way to protect cables from moisture and
abrasion.
(See Bently Nevada Catalog or your local Bently Nevada Sales Representative for details.)
16
