330500 Velomitor Sensor, 330525 Velomitor XA Sensor, 330530 Radiation Resistant Velomitor Sensor Operation Manual
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
Figure 1-4. 3300 System Connections (3300/55 Monitor)
8
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Signal input relay module location
Channel A recorder output
Channel B recorder output
Alert relay contacts
Danger relay contacts
Signal input relay module, dual relays
Channel A Velomitor® Sensor
Channel B Velomitor® Sensor
