Parts List - Linear Technology DC1759A Demo Manual

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 1 CIN1
2 3 CIN2, CIN3, CIN4, CIN5
3 2 COUT1, COUT7
4 2 COUT4, COUT5
5 1 C2
6 2 C5, C7
7 1 C6
8 1 C9
9 4 C13, C14, C15, C16
10 1 Q1
11 4 R1, R3, R22, R26
12 4 R5, R24, R27, R36
13 4 R7, R21, R29, R32
14 4 R9, R12, R15, R18
15 2 R10, R13
16 1 R19
17 1 R25
18 1 R30
19 1 R34
20 1 R37
21 1 U1
Additional Circuits
22 0 COUT2, COUT3, COUT6, COUT8,
23 0 C1
24 0 C3, C4, C8, C10, C11, C12
25 0 R2, R4, R6, R8, R11, R14, R16, R17, R20, R23,
R28, R31, R33, R39, R40
26 0 R35
27 0 R38
Hardware/Components (For Demo Board Only)
28 16 E1, E3-E10, E12-E18
29 3 J1, J2, J3
30 6 J4-J9
31 1 JP1
32 1 JP6
33 3 JP2, JP3, JP4
34 1 JP5
35 4 MTGS at 4 corners
36 6 XJP1-XJP6
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
DEMO MANUAL DC1759A
PART DESCRIPTION
Cap., 150μF, 25V, Aluminum Electr.,
Cap., X5R, 22μF, 25V, 10%, 1210
Cap., 330μF, 6.3V, POSCAP 7343
Cap., X5R, 100μF, 6.3V, 20% 1210
Cap., X7R, 1μF, 25V, 10%, 0805
Cap., X5R, 0.1μF, 25V, 10%, 0603
Cap., 33pF, 10V, 10%, 0603
Cap., 47pF, 10V, 10%, 0603
Cap., X7R, 1μF, 10V, 10%, 0603
N-Channel 30-V Mosfet
Res., Chip, 10Ω, 1%, 0603
Res., Chip, 10k, 1%, 0603
Res., Chip, 0Ω, 1%, 0603
Res., Chip, 60.4k, 1%, 0603
Res., Chip, 6.04k, 1%, 0603
Res., Chip, 8.25k, 1%, 0603
Res., Chip, 13.3k, 1%, 0603
Res., Chip, 191k, 1%, 0603
Res., Chip, 0Ω, 0.5W, 2010
Res., Chip, 0.015Ω, 2W, 2512
LTM4620AEV 15X15X4.41-LGA
OPT 1210
OPT 0805
OPT 0603
OPT 0603
OPT 2010
OPT 2512
TESTPOINT, TURRET, 0.094"
CONN, BNC, 5 PINS
CONN, BANANA JACK, KEYSTONE-575-4
HEADER 4 PIN 0.079 DOUBLE ROW
HEADER 4 PIN 0.079 SINGLE ROW
HEADER 3 PIN 0.079 SINGLE ROW
HEADER 3 PIN 0.079 DOUBLE ROW
STAND-OFF, NYLON 0.50"
SHUNT, 0.079" CENTER
MANUFACTURER/PART NUMBER
SUN ELECT., 25CE150AX
MURATA, GRM32ER61E226KE15
SANYO, 6TPF330M9L
AVX, 12106D107MAT2A
AVX, 08053C105KAT2A
AVX, 06033D104KAT
AVX, 0603ZC330KAT2A
AVX, 0603ZC470KAT2A
AVX, 0603ZC105KAT
VISHAY, SUD50N03-09P
NIC, NRC06F10R0TRF
YAGEO, RC0603FR-0710KL
VISHAY, CRCW06030000Z0ED
VISHAY, CRCW060360K4FKED
YAGEO, RC060FR-0760K4L
VISHAY, CRCW06038K25FKED
VISHAY, CRCW060313K3FKED
VISHAY, CRCW0603191KFKED
TEPRO, RN6083
VISHAY, WSL2512R0150FEA
LINEAR TECH., LTM4620AEV
OPT
OPT
OPT
OPT
OPT
OPT
MILL-MAX, 2501-2-00-80-00-00-07-0
CONNEX 112404
KEYSTONE 575-4
SAMTEC, TMM104-02-L-D
SAMTEC, TMM104-02-L-S
SAMTEC, TMM103-02-L-S
SAMTEC, TMM-103-02-L-D
KEYSTONE, 8833(SNAP-ON)
SAMTEC, 2SN-BK-G
dc1759af
7
