CHANGING TEST SETTINGS

EDITING TEST PARAMETERS
If you wish to edit the test parameters, use the Up or Down arrow keys to
progress through the test parameters menu. The Down arrow key will advance
forward and the Up arrow key will advance backward. The sequence for
forward menu items are Voltage, HI-Limit, LO-Limit, Ramp-UP, Dwell Unit, Dwell
Time, Ramp-DOWN, Frequency (AC Model), Arc Detect, Arc Sense, Ramp-HI
(DC Models), Charge-LO (DC Models), and Connect. To edit the individual
parameters, use the numeric keys to enter the appropriate value. In some cases
the ENTER key will activate or deactivate a particular parameter such as
Connect. After all parameters have been adjusted, press the EXIT key to return
to the Perform Test screen.
TEST TYPE
ACW units
DCW units
PARAMETER
Voltage
HI-Limit (current)
LO-Limit (current)
Ramp-UP
Dwell Unit
Dwell Time
Ramp-DOWN
Frequency
Arc Detect
Arc Sense
Connect
Voltage
HI-Limit
LO-Limit
Ramp-UP
Dwell Unit
Dwell Time
Ramp-DOWN
Arc Detect
Arc Sense
Ramp-HI
Charge-LO
Connect
7
VALUE
1.24kVAC
5.000mA
0.000mA
0.3s
Second
1.0s
0.0s
60Hz
Off
5
OFF
1.5kVDC
5000μA
0.0μA
0.4s
Second
1.0s
0.0s
OFF
5
OFF
0.0μA
OFF
