CHANGING SYSTEM SETTINGS

ADDING A NEW TEST
Press the SETUP key to progress through the menu of System Parameters.
Successive key presses will advance the menu forward. The sequential forward
menu items are:
GPIB address
(Displayed with Option 01)
Command Set
Memory Lock
Use the ENTER key and numeric keys to edit the System Parameters. Press the
EXIT key to return to the Perform Test screen. The system settings are global and
are not specific to any memory location.
SELECTING A MEMORY LOCATION
The HypotMAX is equipped with 50 memory locations, numbers 1 through 50.
Each memory location consists of 1 test and may be linked to perform up to 50
tests in sequence. To select the Memory Location press the MEMORY key. Use
the Numeric Keys to enter the memory location number, and then press the
ENTER key. The program will recall the test parameters stored in this location
and return to the operation mode automatically.
PLC Remote
Fail Stop
Contrast
Alarm
Smart GFI
BUS Remote
