Rockwell Automation 1336 PLUS Instructions

1336 PLUS Language Module
Installation/Replacement
This publication will guide you through installation (or replacement)
of the 1336 PLUS Language Module.
ATTENTION: This drive contains ESD (Electrostatic
!
Discharge) sensitive parts and assemblies. Static control
precautions are required when installing, testing, servicing
or repairing this assembly. Component damage may result
if ESD control procedures are not followed. If you are not
familiar with static control procedures, reference A-B
publication 8000-4.5.2, "Guarding Against Electrostatic
Damage" or any other applicable ESD protection
handbook.
ATTENTION: To avoid a shock hazard, assure that all
!
power to the drive has been removed before proceeding with
the following procedure. In addition, verify that the DC bus
has discharged by measuring across the "+ DC" and "– DC"
terminals of TB1 with a voltmeter. The voltage should be
0.0V DC.
1. Check the version of firmware presently installed in the drive.
If the current version is 1.04 or greater, proceed to step 2.
If you have version 1.03, parameters 111-127 and 180 must be
checked. The value of each parameter must be greater than zero
and less than 212. If any value is outside of this range, reprogram
using the Program mode before proceeding to step 2.
Important: If parameters 127 and/or 180 are set to "0" (zero), these
must be reprogrammed to "1."
If the above is not performed, an "EE Init Read" fault (F53) will
be issued when the drive is powered up with the new Language
Module.
2. Remove and lock-out all incoming power to the drive. Remove
the drive cover.
