What this Option Provides
Where this Kit is Used
What the Kit Contains
1336 PLUS and
(NEMA Type 4/12) Enclosure Kit
The Enclosure Kit provides the required materials to enclose an open
chassis 1336 PLUS or 1336
installed, each Enclosure Kit is designed to meet IP 65 (NEMA Type
4) standards or IP 54 (NEMA Type 12) standards and permit the drive
heatsink to extend outside the enclosure. You must observe the
general installation requirements that are provided in the installation
section of your drive User Manual.
The Enclosure Kit is used in the following ranges:
Frame
Reference
Enclosure Kit Catalog Number Used with 1336 S/F . . .
1
A1, A2, A3
1336S-AFA3, 1336S-AJA3
A4
1336S-AFA4B, 1336S-AJA4B
B1
1336-AFB1A, 1336-AJB1A
1336-AFB1B, 1336-AJB1B
1336-AFB1C, 1336-AJB1C
B2
1336-AFB2A, 1336-AJB2A
1336-AFB2B, 1336-AJB2B
1336-AFB2C, 1336-AJB2C
C
1336-AFCA, 1336-AJCA
1336-AFCB, 1336-AJCB
1336-AFCC, 1336-AJCC
Each IP 65 (NEMA Type 4) Enclosure Kit contains the following:
•
(1) Pre-assembled IP 65 (NEMA Type 4) enclosure with fan
•
(1) IP 65 (NEMA Type 4) permanent adhesive backed gasket.
•
M5 x 0.08 x 10M sems or hex head screws.
Each IP 54 (NEMA Type 12) Enclosure Kit contains the following:
•
(1) Pre-assembled IP 54 (NEMA Type 12) enclosure with fan
•
(1) IP 54 (NEMA Type 12) permanent adhesive backed gasket.
•
10-32 x 3/8 inch sems or hex head self-tap screws.
1
Fans are not required on A1, A2, and A3 frame enclosures.
IP 65/54
PLUS
II
in an enclosure. When properly
PLUS
II
AQF05 - AQF50, BRF05 - BRF50
BRF75 - BRF100
A007
B007 - B015
C007 - C010
A010 - A015
B020 - B030
C015 - C020
A020 - A030
B040 - BX060
C025 - C060
Instructions
1
.
1
.
Advertisement
Related Manuals for Rockwell Automation 1336 PLUS
Summary of Contents for Rockwell Automation 1336 PLUS
- Page 1 (NEMA Type 4/12) Enclosure Kit What this Option Provides The Enclosure Kit provides the required materials to enclose an open chassis 1336 PLUS or 1336 in an enclosure. When properly PLUS installed, each Enclosure Kit is designed to meet IP 65 (NEMA Type 4) standards or IP 54 (NEMA Type 12) standards and permit the drive heatsink to extend outside the enclosure.
- Page 2 1336 PLUS and PLUS II IP 65/54 (NEMA Type 4/12) Enclosure Kit To install the drive, follow these steps: ATTENTION: Electric shock can cause injury or death. Disconnect all power before working on this product. ATTENTION: Drive heatsink surface temperature may be at or near 100 degrees C (212 degrees F).
- Page 3 1336 PLUS and PLUS II IP 65/54 (NEMA Type 4/12) Enclosure Kit IP 65/54 (NEMA Type 4/12) Dimensions See Detail A 12.4 (0.49) Detail B 7.9 (0.31) 12.7 (0.50) 7.1 (0.28) Dia. 12.7 (0.50) 14.3 (0.56) Dia. Typical Top and Bottom Detail A 12.7 (0.50) Dia.
- Page 4 Publication 1336 PLUS-5.66 – May, 1999 P/N 74002-139-01 (01) Supersedes February, 1996 Copyright 1999 Rockwell International Corporation. All rights reserved. Printed in USA.
