Installation Instructions Solid State 24V DC Source Output Module Catalog Number 1762-OB16 Table of Contents Topic Page Additional Resources Description Installation Mounting System Assembly Field Wiring Connections I/O Memory Mapping Specifications North American Hazardous Location Approval Publication 1762-IN011B-EN-P...
Guidelines, publication 1770-4.1. techniques. If you would like a manual, you can: • download a free electronic version from the Internet: http://literature.rockwellautomation.com • purchase a printed manual by contacting your local Allen-Bradley distributor or Rockwell Automation representative Publication 1762-IN011B-EN-P - June 2013...
Solid State 24V DC Source Output Module Description Item Description Item Description upper panel mounting tab bus connector cover lower panel mounting tab flat ribbon cable with bus connector (female pins) I/O diagnostic LEDs terminal block module door with terminal DIN rail latch identification label bus connector with male pins...
Solid State 24V DC Source Output Module Installation 1762 I/O is suitable for use in an industrial environment when installed in accordance with these instructions. Specifically, this equipment is intended for use in clean, dry environments (Pollution degree 2 ) and to circuits not exceeding Over Voltage Category II (IEC 60664-1).
Solid State 24V DC Source Output Module Mounting Do not remove protective debris strip until after the module and all other ATTENTION equipment near the module is mounted and wiring is complete. Once wiring is complete and the module is free of debris, carefully remove protective debris strip.
Solid State 24V DC Source Output Module DIN Rail Mounting The module can be mounted using the following DIN rails: 35 x 7.5 mm (EN 50 022 - 35 x 7.5) or 35 x 15 mm (EN 50 022 - 35 x 15). Before mounting the module on a DIN rail, close the DIN rail latch.
Solid State 24V DC Source Output Module System Assembly The expansion I/O module is attached to the controller or another I/O module by means of a flat ribbon cable after mounting as shown below. Use the pull loop on the connector to disconnect modules. Do not pull on the ribbon cable.
Solid State 24V DC Source Output Module Field Wiring Connections Grounding the Module This product is intended to be mounted to a well-grounded mounting surface such as a metal panel. Refer to Industrial Automation Wiring and Grounding Guidelines, Allen-Bradley publication 1770-4.1, for additional information. Output Wiring Basic wiring of the 1762-OB16 is shown below.
Solid State 24V DC Source Output Module ATTENTION Miswiring of the module to an AC power source will damage the module. Finger-safe cover not shown for clarity. Wiring the Finger-Safe Terminal Block When wiring the terminal block, keep the finger-safe cover in place. 1.
Solid State 24V DC Source Output Module Wire Size and Terminal Screw Torque Each terminal accepts up to two wires with the following restrictions: Wire Type Wire Size Terminal Screw Torque Solid Cu-90 °C (194 °F) #14…22 AWG 0.90 Nm (8 lb-in.) Stranded Cu-90 °C (194 °F) #16…22 AWG...
Solid State 24V DC Source Output Module Specifications General Specifications Specification Value Dimensions, HxWxD 90 x 40.4 x 87 mm (height including mounting tabs is 110 mm) 3.54 x 1.59 x 3.43 in. (height including mounting tabs is 4.33 in.) Approximate Shipping Weight 235 g (0.52 lbs.) (with carton)
Page 12
Solid State 24V DC Source Output Module Output Specifications Specification Value Voltage Category 24V DC Operating Voltage Range 20.4…26.4V DC Number of Outputs Bus Current Draw, max 175 mA @ 5V DC (0.88 W) Heat Dissipation max 2.9 total Watts @ 30 °C (86°F) 2.1 total Watts @ 55 °C (131 °F) Signal Delay (max.) –...
Page 13
Solid State 24V DC Source Output Module Certifications Certification (when product is Value marked) c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada. UL Listed for Class I, Division 2 Group A,B,C,D Hazardous Locations, certified for U.S and Canada. See UL File E334470.
Solid State 24V DC Source Output Module North American Hazardous Location Approval This equipment is suitable for use in Class I, Division 2, Groups A, B, C, D or non-hazardous locations only. The following WARNING statement applies to use in hazardous locations. The following information applies when Informations sur l’utilisation de cet équipement operating this equipment in hazardous...
Page 15
Solid State 24V DC Source Output Module Notes: Publication 1762-IN011B-EN-P - June 2013...
