Code Soft TP-290XIII Programmer's Manual page 24

§
§
§
§
[Default] x = 200, y = 200
[Reference] ESC SP, ESC $, ESC 3, ESC J, ESC W, ESC \, GS $, GS L, GS V, GS W, GS \
37、GS W nL nH
[Format] ASCII
Hex
Decimal
0 ≤ nL ≤ 255
[Range]
0 ≤ nH ≤ 255
[Description] Sets the printing area width to the area specified by nL and nH.
The printing area width is set to [(nL + nH × 256) × horizontal motion unit] inches
左 边距
[Notes]
§
§
§
§
§
§
§
In standard mode, the following commands use x or y, regardless of
character rotation (upside-down or 90° clockwise rotation):
①Commands using x: ESC SP, ESC $, ESC \, FS S, GS L, GS W
②Commands using y: ESC 3, ESC J, GS V
In page mode, the following command use x or y, depending on character
orientation:
①When the print starting position is set to the upper left or lower right of the
printing area using ESC T (data is buffered in the direction perpendicular to
the paper feed direction):
Commands using x: ESC SP, ESC $, ESC W, ESC \, FS S
Commands using y: ESC 3, ESC J, ESC W, GS $, GS \, GS V
②When the print starting position is set to the upper right or lower left of the
printing area using ESC T (data is buffered in the paper feed direction):
Commands using x: ESC 3, ESC J, ESC W, GS $, GS \
Commands using y: ESC SP, ESC $, ESC W, ESC \,FS S, GS V
The command does not affect the previously specified values.
The calculated result from combining this command with others is truncated
to the minimum value of the mechanical pitch.
Set printing area width
GS W
1D 57
29 87
可打印 区域
打印区域宽度
This command is effective only processed at the beginning of the line.
In page mode, the printer performs only internal flag operations.
This command does not affect printing in page mode.
If the [left margin + printing area width] exceeds the printable area, [printable
area width - left margin] is used.
The horizontal and vertical motion units are specified by GS P. Changing the
horizontal and vertical motion units does not affect the current left margin.
The horizontal motion unit (x) is used for calculating the printing area width.
The calculated result is truncated to the minimum value of the mechanical pitch.
THERMAL RECEIPT PRINTER
nL nH
nL nH
nL nH
23
