Code Soft TP-290XIII Programmer's Manual page 17

§
§
§
[Reference] ESC *, FS q, GS /, GS v 0
29、FS q n [xL xH yL yH d1...dk]1...[xL xH yL yH d1...dk]n
[Format] ASCII
Hex
Decimal
1 ≤ n ≤ 255
[Range]
0 ≤ xL ≤ 255
1 ≤ ( xL + xH × 256) ≤ 1023
1 ≤ ( yL + yH × 256) ≤ 288
0 ≤ d ≤ 255
k = ( xL + xH × 256) × ( yL + yH × 256) × 8
Total defined data area = 8096 bytes
[Description] Define the NV bit image specified by n.
§
§
§
[Notes]
§
§
§
§
§
characters, etc.), except upside-down printing mode.
If the downloaded bit-image to be printed exceeds one line, the excess data
is not printed.
This command feeds dots (for the height n of the NV bit-image) in normal
and double-widthmodes, and (for the height n × 2 of the NV bit-image) in
double-height and quadruple modes,regardless of the line spacing specified
by ESC 2 or ESC 3.
After printing the bit image, this command sets the print position to the
beginning of the lineand processes the data that follows as normal data.
FS q
1C 71
28 113
n specifies the number of the defined NV bit image.
xL, xH specifies (xL   x H ×  2 56) ×  8 dots in the horizontal direction for the NV
bit image you are defining.
yL, yH specifies (yL   y H × 256) ×  8 dots in the vertical direction for the NV bit
image you are defining.
It's not recommended to write flashrom frequenty. No more than 10 times a
day.
This command cancels all NV bit images that have already been defined by
this command.The printer can not redefine only one of several data
definitions previously defined. In this case, all data needs to be sent again.
During processing this command, the printer is in BUSY when writing the
data to the NV user memory and stops receiving data. Therefore it is
prohibitted to transmit the data including the real-time commands during the
execution of this command.
NV bit image means a bit image which is defined in a non-volatile memory by
FS q and printed by FS p.
In standard mode, this command is effective only when processed at the
beginning of the line.
THERMAL RECEIPT PRINTER
Define NV bitmap image
n [ xL xH yL yH d1...dk]...[ xL xH yL yH d1...dk]
n [xL xH yL yH d1...dk]...[ xL xH yL yH d1...dk]
n [xL xH yL yH d1...dk]...[ xL xH yL yH d1...dk]
16
