Code Soft TP-290XIII Programmer's Manual page 20

20 32
30 48
40 64
50 80
60 96
70 112
[Notes]
§
§
§
§
§
§
[Default] n = 0
[Reference] ESC !
31、GS * x y d1...d(x × y × 8) Define downloaded bit image
[Format] ASCII
Hex
Decimal
1 ≤ x ≤ 255, 1 ≤ y ≤ 48
[Range]
x × y ≤ 912
0 ≤ d ≤ 255
[Description] Defines a downloaded bit image using the number of dots specified by x and y.
§
§
The number of dots in the horizontal direction is x × 8, and in the vertical direction it is
[Notes]
y × 8.
§
§
§
3
4
5
6
7
8
This command is all characters (alphanumeric and Kanji) effective except
forHRI characters.
If n is outside of the defined range, this command is ignored.
In standard mode, the vertical direction is the paper feed direction, and the
horizontal direction is perpendicular to the paper feed direction. However,
when character orientation changes in 90  c lockwise -rotation mode, the
relationship between vertical and horizontal directions is reversed.
In page mode, vertical and horizontal directions are based on the character
orientation.
When characters are enlarged with different sizes on one line, all the
characters on the line are aligned at the baseline.
The ESC ! command can also turn double-width and double-height modes
on or off. However, the setting of the last received command is effective.
GS *
1D 2A
29
x specifies the number of dots in the horizontal direction.
y specifies the number of dots in the vertical direction.
If x × y is out of the specified range, this command is disabled.
The d indicates bit-image data. Data (d) specifies a bit printed to 1 and not
printed to 0.
The downloaded bit image definition is cleared when:
① ESC @ is executed.
② ESC & is executed.
③ FS q is executed.
