Summary of Contents for DoorHan SHAFT-120
- Page 1 InstallatIon and operatIng manual sHaFt-120...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Table of contents ........................2 2. General information ......................... 3 2.1 Basic functions ........................3 2.2 Specifications ........................4 3. Delivery set ..........................5 4. Safety instructions........................6 5. Tools ............................7 6. Operator components ......................8 7. -
Page 3: General Information
GENERAL INFORMATION 2. GENERAL INFORMATION The electromechanical operator SHAFT-120 of the company “DoorHan” is intended for automation of balanced industrial sectional gates. The electromechanical operator SHAFT-120 is a shaft-type operator with reduction gear in “oil bath”. It consists of a mechanical reducer in “oil bath” and an electric motor with an integral control unit. The reducer and the motor have a common housing. -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS 4. SAFETY INSTRUCTIONS • Read carefully this manual. • Have qualified personnel carry out installation and startup of the operator . • Open and close the gate by hand, make sure, that it moves smoothly. • The gate shall be equipped with balance springs and balanced, otherwise the operator will fail. Before installation of the operator be sure, that the gate is balanced properly and is in a good working condition. -
Page 5: Operator Components
COMPONENTS 6. Operator components Release cord Motor Manual chain Control unit Reducer housing Manual drive unit End switches 7. Installation Before installation make sure that the gate is in good working condition and the torsion springs balance its leaf. Install the operator as described below (Section “On-shaft mounting”... -
Page 6: Wiring
INSTALLATION 7.2 Mounting via the chain operator • Additional accessories for installation can be purchased separately. • Mount the large sprocket on the gate shaft end. • Fix the bracket on the wall according to the length of the chain using dowels. •... -
Page 7: Control Unit Connection
WIRING 5. 3-position control station or key-switch 8.1 Control unit connection (N.O. contact) (terminal block X1 and X2) 220V Jumper for selection Connect 3-position control station to terminals of supply voltage Motor ‘OPEN’, ‘STOP’, ‘CLOSE’ and ‘GND’. 380V Jumper for selection of supply voltage Fuse Important! If 3-position control station is not... -
Page 8: Open Position (Blue Cam)
ADJUSTMENT OF OPEN AND CLOSE POSITIONS Fine adjustment Turning screw for fine adjustment, correct the close position of the gate. • Open and close the gate, make sure, that red cams push the micro-switches and the gate remains in the desired position. •... -
Page 9: Release Operation
11. Release operation The electric operator SHAFT-120 is equipped with a manual chain reducer, which is used for emergency lifting/lowering of the gate in case of power cut. For emergency control, pull the red knob down up to the stop, avoiding in such way automatic actuation of the operator. To return to the automatic control, pull the green knob down up to the stop. -
Page 10: Trouble Shooting
Customer signature Hereby we inform you that your data will be entered in the data- base of the company DoorHan and you will be notified with guarantee registration letter. We also can send you promotional materials and other explanatory materials. - Page 11 NOTES OP ERATOR SH A F T -1 20 INSTAL LAT IO N AND OP E RAT ING MANU AL...
- Page 12 DoorHan thank you for buying our products. We hope you will be satisfied with the quality of our product. If you need any further information about purchasing, distribution and maintenance, contact our regional agents or our central office at the following address:...
