- Page 1 CONTENTS GENERAL INFORMATION SAFETY INSTRUCTIONS OPERATOR UNIT OPERATOR INSTALLATION ELECTRICAL CONNECTIONS MANUAL OPENING MAINTENANCE TROUBLESHOOTING APPENDIX OPERATOR SECTIONAL-500PRO/ 750PRO Installation and Operating Manual Actual versions soft - v 1.0 © DoorHan, 2014 pcb - v 1.0...
-
Page 2: Table Of Contents
2. Remote programming for Doorhan remote controllers ........ -
Page 3: Specifications
ПРАВИЛА БЕЗОПАСНОСТИ УСТРОЙСТВО ПРИВОДА УСТАНОВКА ПРИВОДА ЭЛЕКТРИЧЕСКИЕ ПОДКЛЮЧЕНИЯ ПРОГРАММИРОВАНИЕ ЭЛЕКТРОПРИВОДА ПРОГРАММИРОВАНИЕ ПУЛЬТА ДУ РУЧНОЕ ОТКРЫВАНИЕ ПРИВОД ОБСЛУЖИВАНИЕ ДИАГНОСТИКА НЕИСПРАВНОСТЕЙ SECTIONAL-500PRO Инструкция по монтажу и эксплуатации © DoorHan, 2012 Guide fastening bracket Headroom bracket Straight arm fastening bracket Slotted bushing Fastening set № Name Quantity № Name Quantity 1 Electric operator... -
Page 4: Safety Instructions
You should use additional DoorHan accessories, since the accessories of third party manufacturers can damage the automatic system. DoorHan is not liable for unstable work of the automatic system, if you use safety devices and accessories, produced by other manufacturers without securing approval of DoorHan. -
Page 5: Operator Unit
OPERATOR UNIT RISK OF INJURY! WARNING! Have a qualified technician lay the cables 230 V AC. The cables must be laid in protective corrugated tubes. In case of supply cable damage, use the suitable type of the cable. Cables needed for installation of sectional-500 operator and accessories (if available) Cable 2 × 0.5 mm (photocell transmitter) Cabel 4 × 0.5 mm (photocell receiver) Cable 3 × 1.5 mm (power supply) The cables should be appropriately insulated 3. OPERATOR UNIT 3.1. OVERALL DIMENSIONS 3.2. DRIVE DEVICE Display cover Housing cover LED lamp Display Motor reducer Control board Housing Reference point microswitch Splined bushing... -
Page 6: Operator Installation
OPERATOR INSTALLATION 4. OPERATOR INSTALLATION 4.1. TOOLS Set of spanners Set of drills for concrete Electric drill Set of slotted and cross screwdrivers Pliers Tape measure (folding rule) Set of drills for metal Hacksaw for metal 4.2. REQUIRMENTS TO DOOR INSTALLATION 45 mm P rior to installation check if the door is properly balanced and moves smoothly when automatically operated. M ake sure, that minimal clearance between ... -
Page 7: Track Installation
OPERATOR INSTALLATION 4.4. TRACK INSTALLATION The operator suspension height is determined by the maximum lift of upper edge of the door leaf. After preliminary assembly (see p. 4.3) you can start to install the track: 1. If it is required to shorten a guide, it is necessary to fulfill operations, described in Appendix 1. 2. You should mark a vertical line, corresponding to the horizontal door centre (fig. 5). 3. Y ou should place a lintel mounting bracket (1) in such a way that the distance from upper edge of the open door leaf to lower edge of the track amounted to minimum 10 mm (fig. 5.2) and fix it to the lintel using self-tapping screws (2) (fig. 5.1). 4. You should fasten the track (3) and the lintel mounting bracket by means of a track fixation bolt (4) (fig. 5.3). 5. You should install a U-shaped bracket (5) on the track approximately at a distance 2/3 L and attach it to the ceiling (fig. 5.4). 6. Y ou should install track mounting brackets (6) on the track approximately at a distance 1/3 L and attach them to the ceiling (fig. 5.5). 7. Y ou should install a rod-to-leaf mounting bracket (7) in the middle of the upper aluminium profile of the door leaf and fix it using self-tapping screws (8) (fig. 5.6). 8. Y ou should attach a cranked rod (9) to the rod mounting bracket and fix it by means of a pin axle (10) (fig. 5.7). It is allowed not to mount the cranked rod, if α angle is observed. -
Page 8: Electrical Connections
ELECTRICAL CONNECTIONS 5. ELECTRICAL CONNECTIONS 5.1 Control block specifications Parameters Units Power supply 180-240 V/50-60 Hz Power supply of accessories 24 V DC Maximal current of accessories 200 mA Working temperature range –20…+55 °C Radio control frequency 433,92 MHz Operating logics Automatic/Semi-automatic Connectors Open button/Safety devices Lamp turn-on time 3 min Fuse type Quick cutoff fuse, 230 V, 2.5 А 5.2 Control block wiring diagram WARNING! The cable wires must be protected from contact with any rough or sharp parts. All connections shall be made only when power is off. Photosells Black Antenna LAMP BATTERY 24V Observe the polarity! 24V DC ..–... -
Page 9: Preparation
OPERATOR PROGRAMMING 2. PREPARATION Block the carriage. Turn on power, the indicator of the operator will light, sound signal will be heard. If programming has not been completed, the settings will not be stored. If there is a mistake in one of the settings, you can turn off power and reprogram. 3. UPPER DOOR POSITION Нажимая «+» и «–», установите полотно в необходимое Нажмите «Р» для Press and hold «1» will light Press «P», When pressing «+» and «-», set the door panel into Press «P» to save верхнее положение сохранения информаци down the button «P» «1» will flash upper position required. the information during about 5 sec The setting will be stored only when you program the UPPER door position. The upper position shall be programmed before setting the lower door position. 4. LOW DOOR POSITION Нажмите «+» замигает Нажимая «–» и «+», установите полотно ворот в закрытое Press «+»... -
Page 10: Absolute Cycle Counter
OPERATOR PROGRAMMING 7. ABSOLUTE CYCLE COUNTER Press «+» «5» will light, press The 1st digit will be The 2nd digit will be «P» displayed displayed When entering the 5th point of menu, two digits will be displayed sequentially. After having displayed the digits, the program returns to main menu. The first digit – tens, the second digit – units. The value received is multiplied by 1000 to receive information on amount of cycles driven by the operator. 8. WARNING ALARM SETUP In the case you forgotten to close the door, after 10 minutes a warning alarm will sound. This signal will be turned off automatically after the door will be closed. The factory setting of this function is “0” – the function is off. Press «+» «6» will light, When pressing «+» and «-», select a function Press «P» to save the press «P» value: «0» – off, «1» - on information 9. AUTOMATIC CLOSING Нажмите «+» — Нажмите «P» Press «+», « Press «P» When pressing «+» and «-», select a function value: «0» - Press «P» to save the загорится «7» 7» will light no automatic closing, «1» - pause 30 sec, «2» - pause information 60 sec ..., «8» - pause 240 sec. 10. MAINTENANCE COUNTER AFTER 2000 CYCLES (FACTORY SETTING: «0» – THE FUNCTION IS OFF) Нажмите... -
Page 11: Remote Control Programming
REMOTE CONTROL PROGRAMMING 5.4. REMOTE CONTROL PROGRAMMING 1. TO ADD A REMOTE CONTROL 1. Press and hold the «R», until the display indicator lights «point». 2. Select on the control panel the button, with the help of which you will control the operator’s work, and press it twice. 3. Repeat above operations for other remote controls (maximum quantity — 20 pcs.). 4. All the remote controls will be added sequentially into the control block. 5. When the maximum quantity of remote controls is exceeded; three long beeps will sound. 2. REMOTE PROGRAMMING FOR DOORHAN REMOTE CONTROLLERS 1. To press and hold the button «2» of the programmed remote control. 2. Without releasing the pressed button «2», to press and hold the button «1» of the remote control. 3. Release the buttons pressed. 4. Press the remote control button already set up. 5. On the new remote control, select a button with the help of which you will control the operator’s work, and press it twice. A beep will sound. NOTE It is possible to add all four control buttons into the operator. 3. MARKING REMOTE CONTROL BUTTONS DOORHAN 4. TO ERASE A REMOTE CONTROL To delete the remote controls from the receiver memory, press and hold down the button “R” for 8–10 seconds until the long beep will sound, what means erasing a remote control in the operator. -
Page 12: Manual Opening
MANUAL OPENING 6. MANUAL OPENING OPENING BY MEANS OF INTEGRATED CARRIAGE RELEASING DEVICE Manual disengagement of automatic system Manual door control Figure Locked position Pull the cord down and Unlocked position move the rod to the position shown in the Figure Automatic door control Figure Unlocked position Pull the cord down and Locked position move the rod to the position shown in the Figure In the event of main power failure In the event of main power failure, the operator can be switched to manual control. To do this, pull down the releasing device cord. The carriage should withdraw from the engagement, amd after that the door can be operated manually (Fig. 7). When main power is restored When main power is restored, the operator is to be set to automatic control. To do this, move the carriage into the locked position by pulling the releasing device cord to youself (Fig. 8). After this, trigger a signal from the remote control or control button, wait till the carriage clutch with chain (belt). IMPORTANT! When the carriage is blocked, the door will move automatically only after the carriage meshes with the chain support. -
Page 13: Maintenance
When carrying out maintenance, it is recommended to use DoorHan original spare parts. Carry out maintenance of the automatic system at least every six months. Regularly check if the door is properly balanced and moves smoothly when automatically operated. Regularly check if the safety devices are in good working condition. I n case of power failure you may need to restore operator’s settings, In case of a power outage, you may need to restore the settings of the drive. To do this, make a complete cycle of opening \ closing the door. In case of power failure the door will stop. As soon as power supply is restored you can control the operator as usual. After expiration of life time, the item shall be delivered in a specialized disposal point! I f you have lost this Manual, you may request for the duplicate copy to the following address: Kralovsky VRCH 2018, Kadan, 43201, Czech Republic, or by e m ail: europe@doorhan.com. T he producer (DoorHan) does not supervise the installation of operators, or carry out their maintenance, thus DoorHan cannot be held liable for safety of installation, operation and maintenance of the equipment. 8. TROUBLESHOOTING Symptom Possible reason Possible solution 1. No power 1. Turn on the power Operator does not run 2. Fuse is broken 2. Replace the fuse Remote control is not entered. Re-entry the remote control Remote control does not run Remote control battery is discharged... -
Page 14: Appendix
APPENDIX APPENDIX GUIDE CUTTING 1. Unpack a guide and inspect it. Make sure that the guide is not damaged. If you have found any damages, please contact the supplier. 2. Disassemble a chain tensioner mechanism, pos. 1 (fig. 1). Fig. 1 3. Unfasten screws of a sprocket holder, pos. 2 (fig. 2). Fig. 2 4. Remove a chain with a carriage mechanism, pos. 3 (fig. 3). Fig. 3... - Page 15 APPENDIX 5. Disassemble a support, pos. 4, into two parts (fig. 4). Fig. 4 6. Cut the guide and shorten the chain to the required dimensions (fig. 5). Fig. 5 7. After cutting assemble the guide in reverse order.
- Page 16 FOR NOTES...
- Page 17 FOR NOTES...
- Page 18 We very much appreciate that you have chosen the product manufactured by our company and believe that you will be satisfied with its quality. For information on purchasing, distribution and servicing contact DoorHan central office at: Kralovsky VRCH 2018, Kadan, 43201, Czech Republic Telephone: +420 474 319 111 E-mail: europe@doorhan.com www.doorhan.cz...
