Summary of Contents for DoorHan SHAFT-30
- Page 1 GENERAL INFORMATION SAFETY INSTRUCTIONS OPERATOR UNIT OPERATOR INSTALLATION ADJUSTMENT OF EXTREME POSITION MANUAL CONTROL OF OPERATOR MAINTENANCE TROUBLESHOOTING OPERATOR SHAFT-30 IP65 Installation and Operating Manual © DoorHan, 2014...
-
Page 2: Table Of Contents
8. TROUBLESHOOTING ................9 1. GENERAL INFORMATION The electromechanical shaft operator Shaft-30 was designed for automation of industrial sectional doors. It consists of a mechanical reducer in “oil bath” and an electric motor with integral control unit. The reducer and the motor have common casing. -
Page 3: Technical Specifications
Save these instructions. Follow all instructions since incorrect installation can lead to severe injury. Shaft-30 was designed for automation of industrial sectional doors. Do not use the operator for other than intended purposes. DoorHan shall not be held responsible in case of injury caused by misuse of the product. - Page 4 Do not use the operator if it needs repair or adjustment as installation defects or unbalanced door can cause injury. DoorHan shall not be held liable in case of improper installation of the item and damage arisen during operation. ...
-
Page 5: Operator Unit
OPERATOR UNIT 3. OPERATOR UNIT 352,5 Reducer casing Cable Output shaft Wiring terminal block Motor Release handle Hand chain components Limit switch Hand chain 4. OPERATOR INSTALLATION 4.1. TOOLS Set of spanners Set of drills for concrete Electric drill Set of slotted and cross screwdrivers Pliers Tape measure (folding rule) Set of drills for metal... -
Page 6: Installation Via Chain Drive
ADJUSTMENT OF EXTREME POSITIONS 4.3. INSTALLATION VIA CHAIN DRIVE • Additional accessories for installation (bracket, large and small sprockets, chain) are purchased separately. Install the large sprocket on the door shaft end. • • Fix the bracket on the wall according to the length of the chain using dowels. •... -
Page 7: Open Position (Green Cam)
ADJUSTMENT OF EXTREME POSITIONS 5.2. OPEN POSITION (GREEN CAM) Coarse adjustment Make sure, that the operator is fixed rigidly; put the door in fully closed position. • • Loosen the screw for coarse adjustment of green cam, then turn it so, that the microswitches are pushed, then tighten the screw. -
Page 8: Manual Control Of Operator
6.2. CONTROL WITH CHAIN The Shaft-30 electric operator is equipped with a manual chain reducer, which is used for emergency lifting/lowering of the door in case of a power cut. Pull the chain to operate the door in case of emergency. -
Page 9: Troubleshooting
TROUBLESHOOTING 8. TROUBLESHOOTING Problem Possible reason Remedy Power is off Make sure, that the power is on Obstruction to the door movement Remove the obstruction Operator does not run Poor connection of electric wires Check reliability of electric wiring connection The operator is released Engage the operator After the manual chain has been used the operator... - Page 10 NOTES...
- Page 11 NOTES...
- Page 12 We very much appreciate that you have chosen the product manufactured by our company and believe that you will be satisfied with its quality. For information on purchasing, distribution and servicing contact DoorHan central office at: Kralovsky VRCH 2018, Kadan, 43201, Czech Republic Telephone: +420 474 319 111 E-mail: europe@doorhan.com...
