Operation (Temperature Control) - Symmons Unity S-6603 Operation & Maintenance Manual

Installation
9) Remove cover of hand shower cradle (I). Install cradle
and mounting plate (J). Secure with three screws (K).
Replace cover on hand shower cradle.
K

Operation (Temperature Control)

1) Turn shower handle counterclock-
wise approximately 1/4 turn to put
valve in cold position.
Operation (Diverter Control)
1) Turn diverter handle left for tub spout operation.
I
J
2) Turn shower handle counterclock-
wise approximately 1/2 turn to put
valve in warm position.
10) Attach hand shower (H) to hose (O). Attach hose (O) to
vacuum breaker (N). Connect vacuum breaker (N) to
wall ell (L). Turn clockwise to tighten.
H
O
3) Turn shower handle counterclock-
2) Turn diverter handle right for showerhead operation.
5
L
N
O
wise approximately 3/4 turn to put
valve in hot position.
