Operation (Temperature Control); Troubleshooting Chart - Symmons Identity Series Operation & Maintenance Manual

Operation (Temperature Control)

1) Turn shower handle counter-
clockwise approximately 1/4 turn
to put valve in cold position.
Operation (Diverter Control for 6702 only)
1) Diverter lever in down position for
tub spout operation.

Troubleshooting Chart

Problem
Finish is spotting.
Symmons Industries, Inc.
Copyright © 2017 Symmons Industries, Inc.
2) Turn shower handle counter-
clockwise approximately 1/2 turn
to put valve in warm position.
Cause
Elements in water supply may cause
water staining on nish.
31 Brooks Drive Braintree, MA 02184
symmons.com
3) Turn shower handle counter-
clockwise approximately 3/4 turn
to put valve in hot position.
2) Diverter lever in up position for
shower operation.
Clean nished trim area with a soft
cloth using mild soap and water or a
non-abrasive cleaner and then quickly
Phone: (800) 796-6667
gethelp@symmons.com ZV-3196 REV B
Solution
rinse with water.
Fax: (800) 961-9621
021617
