Symmons Naru S-4104-TRM Operation & Maintenance Manual

Tub/hand shower trim

Advertisement

S-4104-TRM
Naru
Tub/Hand Shower Trim
Operation & Maintenance Manual
Model Numbers
S-4104-TRM
Tub/Hand Shower Trim
Modifications
-1.5
1.5 gpm (5.7 L/min) flow restrictor
-2.0
2.0 gpm (7.6 L/min) flow restrictor
-412HSB
30" slide bar in place of wall cradle on
hand shower units
-PNL
Polished nickel finish
-STN
Satin nickel finish
Note: Append appropriate -suffix to model number.
Symmons Industries, Inc.
©2014 Symmons Industries, Inc.
Specifications
Tub/hand shower trim with lever handle and secondary
integral diverter handle includes wall connection, cradle
for hand shower mounting, non-diverter tub spout, in-
line vacuum breaker, flexible metal hose and 3 mode
hand shower with 2.5 gpm (9.5 L/min) flow restrictor.
Components made from metal and nonmetallic materials
plated in standard polished chrome finish.
Compliance
-ASME A112.18.1; CSA B125.1
Warranty
Limited Lifetime - to the original end purchaser in
consumer installations.
5 Years - for commercial installations.
Refer to www.symmons.com/warranty for complete
warranty information.
31 Brooks Drive
Braintree, MA 02184
www.symmons.com
gethelp@symmons.com
(800)796-6667
Fax: (800)961-9621
ZV-3070 REV 0 09/25/14
