Mod 101 Manual page 63

Test Point DC Voltage
"HV" 521 VDC
"B" 492 VDC
"C" 478 VDC
"D" 482 VDC
"E" 468 VDC
"V3 cathode" 34.6 mVDC
See Assembly Drawing 15
E
T4
100K
100K
See Assembly Drawing 22
FILTER SECTION (INSIDE)
AC Voltage
2 VAC
0 VAC
0 VAC
0 VAC
0 VAC
0 VAC
B
D
82K
100K
Voltages measured from test point to ground
with no signal, bias pot turned all the way
to cold and the following front panel
settings:
POWER:
STANDBY:
BASS:
TREBLE:
VOLUME:
HV
See Assembly Drawing 22
See Assembly Drawing 22
4
ON
(UP POSITION)
"0"
"0"
"0"
T6
470
470
C
V3
1*
V3
cathode
A
