Upholstered Bench
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
PART LIST
A.
Cushion
1 Pc.
B.
Top
1 Pc.
F.
Base
1 Pc.
HARDWARE LIST
Hex Wrench
1 Pc.
Small
Hex Wrench
Spring Wrench
1 Pc.
8 Pcs.(+1 extra)
Tools required for assembly : Phillips screwdriver
Home Styles Consumer Assistance: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319
Side Panel
1 Pc.
H.
Leg
4 Pcs.
M3x15
Wood Screw
Magnet
(for Magnet)
2 Pcs.
4 Pcs.(+1 extra)
M6x50
Flat Wrench
Head Cap Bolt (long)
8 Pcs.(+1 extra)
8 Pcs.(+1 extra)
C.
G.
Back Panel
1 Pc.
I.
Leg
1 Pc.
Pull Handle
2 Pcs.
M3x12
Wood Screw
8 Pcs.(+1 extra)
Tools recommended for assembly : Level
D.
Side Panel
1 Pc.
Middle Panel
J.
K.
Door
Door
1 Pc.
1 Pc.
Machine Screw
4 Pcs.(+1 extra)
M3x19
Wood Screw
One Left Support
(long)
One Right Support
8 Pcs.(+1 extra)
2 Pcs.
E.
1 Pc.
