Bar Stool
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damage occurring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List
A.
Seat
1 Pc.
E.
Side Stretcher
1 Pc.
F.
Side Stretcher
1 Pc.
Hardware List
Hex Wrench
1 Pc.
Small Hex Wrench
1 Pc.
Tools required for assembly : Phillips screwdriver
M3.5x40
Wood Screw
6 Pcs. (+1 extra)
M6x40
Head Cap Bolt (short)
3 Pcs.(+1 extra)
Home Styles Consumer Assistance: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319
B.
Leg
1 Pc.
G.
Front Stretcher
1 Pc.
M6x50
Head Cap Bolt
4 Pcs. (+1 extra)
M6x70
Head Cap Bolt (long)
4 Pcs. (+1 extra)
C.
Leg
1 Pc.
D.
Back Frame
1 Pc.
Flat Washer
11 Pcs. (+1 extra)
Spring Washer
11 Pcs. (+1 extra)
