Ology Worksurfaces without Overhang
4
Orient sling support bracket on center of CPU
and tighten straps.
NOTE: Long side of sling support bracket
should be placed nearest the side of the desk.
4
5
Align the mounted bolt with the slot in the base bracket
and slide up and to the rear into position.
LONG SIDE
OF SLING
SUPPORT
BRACKET
6
Insert second bolt through the empty hole in the sling
support bracket.
7
Tighten both bolts.
5
NUT
BOLT
6
Page 5 of 7
21078501 Rev D
