NOTE: Please count and inspect all pieces before disposing of any carton or packing materials.
When ordering components, specific color and/or size information may be required.
Contact a Mayline Customer Service Representative. 1-800-822-8037
COMPONENTS:
REF. #
QTY.
DESCRIPTION
1
3
END ASSEMBLY
2
2
UPPER RAIL
3
1
UPPER RAIL LEFT
4
1
UPPER RAIL RIGHT
5
1
FOOT RAIL
6
1
TOP
HARDWARE BAG PART No A8172:
REF. # QTY. DESCRIPTION
E1
17
1/4-28 x 3/8
MACHINE SCREW
E2
17
1/4-28 KEPS NUT
E3
30
10 x 3/4 SCREW
ASSEMBLY INSTRUCTIONS
TEAM TABLE
PART No.
CALL**
CALL**
CALL**
CALL**
CALL**
CALL~~*
PART No.
X156*
T25*
X11*
* Individual Items, Order by part number.
** Denotes Color Code
~~Denotes Size
(1)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Mayline Ranger Team Table
Summary of Contents for Mayline Ranger Team Table
- Page 1 NOTE: Please count and inspect all pieces before disposing of any carton or packing materials. When ordering components, specific color and/or size information may be required. Contact a Mayline Customer Service Representative. 1-800-822-8037 COMPONENTS: * Individual Items, Order by part number.
- Page 2 1. Assemble the two End Assemblies (1) to the two Upper Rails (2) with two Screws (E1) and two Nuts (E2) per leg as shown. DO NOT tighten screws at this time. 2. Assemble the Foot Rail (5) to the end assemblies with two Screws (E1) and two Nuts (E2) per leg as shown.
- Page 3 5. Place Top (6) face down on a clean flat surface. 6. Line up all pilot holes and assemble Frame Assemblies to Top using Screws (E3) as shown. 7. Turn assembled table to an upright position. MAYLINE recommends that two people perform this task.
