MOTOR CONNECTIONS (CONT'D)
Multi-Mode
J9
1 F.G.
2
[COMM_A]
3 [IN7] GPI
4 [IN8] GPI
5 [IN9] GPI
6
[IN10] GPI
7 [COMM_B]
8 [IN11] GPI
9 [IN12] GPI
10 [IN13] GPI
11
[IN14] GPI
12
[OUT5+] GPI
13
[OUT5-] GPI
14
[OUT4+] GPI
15 [OUT4-] GPI
BRAKE
Control Power Supply
Required for
Drive Operation
+
+24 Vdc
0.5 Adc
-
Drive mounting screw
noTES:
1) The total output current from the +5 Vdc supply to J7-20 cannot exceed 400 mAdc
