InSTALLATIon
AC Mains
90~264 Vac
47~63 Hz
1 or 3 ph.
Edge Filter
Motor
(Optional)
Regen
Resistor
(Optional)
Copley Controls, 20 Dan Road, Canton, MA 02021, USA
Tech Support: E-mail: sales@copleycontrols.com, Internet: http://www.copleycontrols.com
Xenus
Plus
Line Filter
+24 Vdc
Power
Supply
EtherCAT
CME 2
RS-232
(DTE)
EtherCAT
Controller
or
PLC
Quad A/B
Encoder
Tel: 781-828-8090
ASCII
Control
Master
EtherCAT
Slaves
Sin/Cos
Absolute
Resolver
Encoder
Encoder
Fax: 781-828-6547
Page 19 of 26
