Split Screen HDMI Video and Full Screen PC Inputs
The Split Screen Video signal is received via the HDMI cable located on the rear of your Merlin Pro
Monitor which is featured on Page 24 of the Merlin Pro User Manual. This is the same port that is
used for the Merlin Pro PC Input Mode. If you would like to alternate between split screen and Full
Screen HDMI Input utilize the Console shortcut as indicated below. This provides flexibility
between whether or not you view your Merlin Pro CCTV Image, Split Screen Image or Full Screen
HDMI Video Source.
HDMI
This shortcut toggles between the Full Screen HDMI Image (using your Merlin Pro like a computer
monitor) and Full Screen CCTV or Split Screen Image.
5
