User Manual
IP65 Stainless P-Cap Panel PC
15/17/19/21.5/23.8"
Intel® Core™ i5-7200U Kaby Lake
Quick Start Guide
Version 1.2
Document Part Number: 91521110102W
Please read this instructions before operating the device and retain them for future reference.
Model No.:
R15IK3S-SPC3
R17IK3S-SPA1
R19IK3S-SPM1
W22IK3S-SPA3
W24IK3S-SPA2
Advertisement
Table of Contents
Related Manuals for Winmate R15IK3S-SPC3
Summary of Contents for Winmate R15IK3S-SPC3
- Page 1 IP65 Stainless P-Cap Panel PC 15/17/19/21.5/23.8” Intel® Core™ i5-7200U Kaby Lake Model No.: R15IK3S-SPC3 R17IK3S-SPA1 R19IK3S-SPM1 W22IK3S-SPA3 W24IK3S-SPA2 Quick Start Guide Version 1.2 Document Part Number: 91521110102W Please read this instructions before operating the device and retain them for future reference.
-
Page 2: Table Of Contents
3.2 Connector Pin Assignments 3.2.1 Power Cable 3.2.2 Serial Cable 3.2.3 Ethernet Cable 3.2.4 USB 2.0 Cable 3.3 Mounting 3.3.1 VESA Mounting 3.3.2 Yoke Mounting Appendix Appendix A: Hardware Specifications Appendix B: Cleaning the Monitor Appendix C: Winmate Software Development Kit... - Page 3 FCC Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received including interference that may cause undesired operation.
- Page 4 Brand and product names are trademarks or registered trademarks of their respective owners. Disclaimer Winmate Inc. reserve the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance.
- Page 5 Chapter 1: Introduction Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings. The following is an example of each type of advisory. Note: A note is used to emphasize helpful information Important:...
-
Page 6: Chapter 1: Introduction
P-CAP multi-touch screen supports glove mode and provides even more convenience for the operator. Winmate IP65 Flat Stainless P-CAP Panel PC goes beyond that of the standard industrial panel computers with elegant, edge-to-edge design, rugged construction, powerful performance, and flexible mounting options. -
Page 7: Package Content
Chapter 1: Introduction 1.2 Package Content Carefully remove the box and unpack your device. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately. Standard shipment list: ... -
Page 8: Product Overview
IP65 Stainless P-Cap Panel PC Quick Start Guide 1.3 Product Overview This section contains mechanical drawing of the Panel PC. Notice that this is a simplified drawing and some components are not marked in detail. 1.3.1 Dimensions 15" Unit: mm Dimensions : 378 x 301 x 56.4 1.3.2 Dimensions 17”... -
Page 9: Dimensions 19
Chapter 1: Introduction 1.3.3 Dimensions 19” Unit: mm Dimensions : 467.4 x 392 x 56.6 1.3.4 Dimensions 21.5” Unit: mm Dimensions : 541 x 337 x 53... -
Page 10: Dimensions 23.8
IP65 Stainless P-Cap Panel PC Quick Start Guide 1.3.5 Dimensions 23.8” Unit: mm Dimensions : 620 x 390 x 60 1.4 Physical Buttons and LED Indicators Physical buttons and LED indicators located on the rear side of the Panel PC. Physical Buttons Icon Button... -
Page 11: Connectors
Chapter 1: Introduction 1.5 Connectors IP65 Flat Stainless P-CAP Panel PC has IP65 type connectors with protection cap. -
Page 12: Chapter 2: Getting Started
IP65 Stainless P-Cap Panel PC Quick Start Guide Chapter 2: Getting Started 2.1 Turning On and Off Your Device To turn on your device: 1. Connect the AC adapter to the DC-in jack connector located on the back side of the Panel PC. -
Page 13: How To Enable Watchdog
2.2 How to Enable Watchdog To enable Watchdog, you need to download Winmate Watchdog utility. Find more information on Watchdog in “Watchdog Guide” that you can download from Winmate Download Center or File Share. Refer to the User Manual for more details. -
Page 14: Chapter 3: Installation
IP65 Stainless P-Cap Panel PC Quick Start Guide Chapter 3: Installation 3.1 Wiring Requirements The following common safety precautions should be observed before installing any electronic device: Strive to use separate, non-intersecting paths to route power and networking wires. If power wiring and device wiring paths must cross make sure the wires are perpendicular at the intersection point. -
Page 15: Connector Pin Assignments
Chapter 3: Installation 3.2 Connector Pin Assignments This Panel PC is equipped with four M25 type connectors which are waterproof. Use only the cables that are included in the package. The pin assignments of the cables are as follows. 3.2.1 Power Cable The IP65 Stainless P-Cap Panel PC has M25 type connectors. -
Page 16: Serial Cable
IP65 Stainless P-Cap Panel PC Quick Start Guide 3.2.2 Serial Cable The IP65 Stainless P-Cap Panel PC has M25 type serial port connector. Use serial cable to connect serial interfaces. -
Page 17: Ethernet Cable
Chapter 3: Installation 3.2.3 Ethernet Cable The IP65 Stainless P-Cap Panel PC has M25 type Ethernet connector. Use Ethernet cable to connect the Panel PC to the Internet. -
Page 18: Usb 2.0 Cable
IP65 Stainless P-Cap Panel PC Quick Start Guide 3.2.4 USB 2.0 Cable The IP65 Stainless P-Cap Panel PC has M25 type USB 2.0 connector. Use USB 2.0 cable to connect external devices such as mouse or keyboard to the Panel PC. -
Page 19: Mounting
3.3.1 VESA Mounting The Panel PC has VESA mount holes on the rear side. Follow instructions below to mount the unit with VESA Mount bracket (not supplied by Winmate). Size VESA Plate Screw Hole... -
Page 20: Yoke Mounting
IP65 Stainless P-Cap Panel PC Quick Start Guide 3.3.2 Yoke Mounting Yoke Mount solution allows installing the Panel PC with the bracket (not supplied by Winmate). Mounting instruction: 1. Place the Panel PC on the bracket stand, aiming screw holes for each other. -
Page 21: Appendix
Appendix Appendix Appendix A: Hardware Specifications Model Name R15IK3S- R17IK3S- R19IK3S- W22IK3S- W24IK3S- SPC3 SPA1 SPM1 SPA3 SPA2 Display 15” 17” 19” 21.5” 23.8” Size Resolution 1024 x 768 1280 x 1024 1280 x 1024 1920 x 1080 1920 x 1080 250 ����/��... - Page 22 IP65 Stainless P-Cap Panel PC Quick Start Guide Model Name R15IK3S- R17IK3S- R19IK3S- W24IK3S- W22IK3S-SPA3 SPC3 SPA1 SPM1 SPA2 Input/ Output Connectors 1 x RJ45 - 1 x RJ45 - 1 x RJ45 - 1 x RJ45 - 1 x RJ45 - Ethernet LAN 10/100/1000 10/100/1000...
-
Page 23: Appendix B: Cleaning The Monitor
Don not use oil directly on the display screen. If droplets are allowed to drop on the screen, permanent staining or discoloration may occur. Appendix C: Winmate Software Development Kit Winmate provides the following SDK and Utilities for the IP65 Stainless P-Cap Panel PC. Item File Type... - Page 24 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C www.winmate.com Copyright © Winmate Inc. All rights reserved.
