Remove the PSoC 3 Development Kit from
the package.
3
Plug the USB cable into your PC and the
onboard programming USB port (J1).
5
Insert the PSoC 3 Development Kit CD.
Install PSoC Creator and the kit software.
®
PS
C
3 DEVELOPMENT KIT
O
QUICK START GUIDE
2
Plug the LCD module into port P8.
4
Vary the R56 potentiometer. The voltage is
displayed with a 20-bit resolution on the LCD
module.
6
Launch PSoC Creator.
Open the code examples from the Start Page.
