Summary of Contents for Tyco Electronics GPRA1
- Page 1 AMP General Purpose Rectangular (GPR) Connectors...
-
Page 2: Table Of Contents
General Purpose Rectangular (GPR) Connectors Table of Contents Introduction ………………………………………………………………………………………3-4 Performance Characteristics………………………………………………………………………5 GPRA1 Shell Descriptive Part Numbers and Dimensions …………………………………6-7 GPRB1 Shell Descriptive Part Numbers and Dimensions …………………………………8-9 GPRB2 Horizontal Shells ……………………………………………………………………10-12 GPRB2 Vertical (Square) Shells …………………………………………………………………13 Insert Descriptive Part Numbers ……………………………………………………………14-18 Insert Arrangements………………………………………………………………………………19... -
Page 3: Introduction
General Purpose Rectangular (GPR) Connectors Introduction Product Facts A Smart Connector New Features A high density solution Tyco Electronics is recog- Connector Interface Insert Arrangements ■ compared to circular nized in the Aerospace and Connectors for Gallery Insert • New insert configurations for... -
Page 4: Introduction
General Purpose Rectangular (GPR) Connectors Introduction (Continued) GPRA1 2 quarter-turn fasteners 16 keying positions Max. density: 20 x #22 contacts GPRB1 2 quarter-turn fasteners 16 keying positions Max. density: 40 x #22 contacts GPRB2 1 central jackscrew/jacknut 12 keying positions Max. -
Page 5: Performance Characteristics
Random Vibration — Ground Block 88 N [20 lbs.] 0.3 mm [.012 in.] GPRA1/GPRB1 — 20g (MIL-STD-1344/Method 2005.1, test condition 4) 53.4 N [12 lbs.] 0.38 mm [.015 in.] GPRB2 — 41.7g (MIL-STD-1344/Method 2005.1, test condition 6) 89 N [20 lbs.] 0.38 mm [.015 in.]... - Page 6 General Purpose Rectangular (GPR) Connectors GPRA1 Shell Descriptive Part Number Format Descriptive Part GPRA 1 Numbering System Use this guide to construct I – GPRA Series descriptive part numbers for GPRA1 shells. Refer to II – Shell Size table below for the corre- sponding Tyco Electronics 1 —...
- Page 7 General Purpose Rectangular (GPR) Connectors GPRA1 Shell Dimensions Receptacle Without Grounding Block Plug Without Grounding Block GPRA1RM05N GPRA1PB05N Single Panel Cut Out (See Note 2) Plug With Grounding Block GPRA1WB05N Receptacle With Grounding Block GPRA1ZM05N Note 1: Maximum dimension for inserts with grommets (Part Number GPRAE and GPRAH)
- Page 8 I – GPRB Series descriptive part numbers for GPRB1 shells. Refer to II – Shell Size table below for the corre- sponding Tyco Electronics 1 — Shell size 1 (1 cavity shell) Part Number. III – Shell Style P — Plug R —...
- Page 9 General Purpose Rectangular (GPR) Connectors GPRB1 Shell Dimensions Plug Without Grounding Block GPRB1PB05N Receptacle Without Grounding Block GPRB1RM05N Single Panel Cut Out (See Note 2) Plug With Grounding Block Receptacle With Grounding Block GPRB1WB05N GPRB1ZM05N Note 1: Maximum dimension for inserts with grommets (Part Number GPRBE and GPRBH) Multiple Panel Cut Out Note 2: Rear mounting side view with key post oriented to the upper side (receptacle only) (See Note 2)
-
Page 10: Gprb2 Horizontal Shells
GPRB2 shells. Refer to II – Shell Size page 11 for the correspond- ing Tyco Electronics 2 — Shell size 2 (2 cavities shell) Part Number. III – Shell Style P — Plug (see note 1) H —... - Page 11 General Purpose Rectangular (GPR) Connectors GPRB2 (Horizontal) Shell Descriptive Part Number Format (Continued) Locking & Descriptive Tyco Electronics Size Style Modification Polarization Polarization Hardware Plating Part Number Part Number Device GPRB2PB3N 1738244-1 Kit: Shell & A-F Hardware Unassembled GPRB2PB12N 1738245-1...
-
Page 12: Gprb2 Horizontal Shells
General Purpose Rectangular (GPR) Connectors GPRB2 (Horizontal) Shell Dimensions Plug Without Grounding Block Receptacle Without Grounding Block GPRB2PB3N GPRB2HD3N Receptacle Plug With Grounding Block With Grounding Block GPRB2ZA3N GPRB2WB3N Grounding Block A solution for High Intensity Radiated Electromagnetic Frequencies. The patented design provides a direct Panel Cut Out grounding to the shell. -
Page 13: Gprb2 Vertical (Square) Shells
General Purpose Rectangular (GPR) Connectors GPRB2 Vertical (Square) Shell and Strain Relief Dimensions 10.65 min. (1.627±.004) Shell Kits with Two (0.419 min.) 13.20 ref. (0.520 ref.) 3.10 GROUNDING SPRING Cavities for Key-A Inserts 11.15 ref. (0.122) (0.439 ref.) 5.20 34.68±0.25 (0.205) (1.365±.009) Kit: Shell &... -
Page 14: Insert Descriptive Part Numbers
Descriptive Part GPRA E Numbering System Use this guide to construct GPRA Series descriptive part numbers Inserts for GPRA1 shells (see note 1 and 3) for GPRA & B inserts. Refer to pages 15–18 for Class the corresponding Tyco Electronics Part E —... - Page 15 General Purpose Rectangular (GPR) Connectors Insert Descriptive Part Number Format (Continued) GPRA Insert Part Numbers Contact Descriptive Tyco Electronics Series Contact Type Classification Keying Arrangement Part Number Part Number Dummy Insert GPRAN00 1738049-1 Environmental, with Rear Grommet & Interfacial Seal...
- Page 16 General Purpose Rectangular (GPR) Connectors Insert Descriptive Part Number Format (Continued) GPRB Insert Part Numbers Contact Descriptive Tyco Electronics Series Contact Type Classification Keying Arrangement Part Number Part Number Dummy Insert GPRBN00 1738085-1 GPRBEC3PA 1738086-1 Environmental, with Rear Grommet & Interfacial Seal...
- Page 17 General Purpose Rectangular (GPR) Connectors Insert Descriptive Part Number Format (Continued) GPRB Insert Part Numbers (Continued) Contact Descriptive Tyco Electronics Series Contact Type Classification Keying Arrangement Part Number Part Number GPRBE20C1PA 1738136-1 Environmental, with Rear Grommet & Interfacial Seal GPRBE20C1PB...
-
Page 18: Insert Descriptive Part Numbers
General Purpose Rectangular (GPR) Connectors Insert Descriptive Part Number Format (Continued) GPRB Insert Part Numbers (Continued) Contact Descriptive Tyco Electronics Series Contact Type Classification Keying Arrangement Part Number Part Number GPRBE25Q1PA 1811121-1 Environmental, with Rear Grommet & Interfacial Seal GPRBE25Q1PB... -
Page 19: Insert Arrangements
General Purpose Rectangular (GPR) Connectors Insert Arrangements GPRA Inserts Dummy Insert 1 x Size 5 Contacts 2 x Size 15 or 16 Contacts 3 x Size 20 Contacts 2 x Size 12 Contacts 6 x Size 15 or 16 Contacts 14 x Size 20 Contacts 8 x Size 22 Contacts 12 x Size 22 Contacts... -
Page 20: Insert Assemblies For High Speed Applications
1918617-1 1828200-1 Tyco Electronics has extensive Rugged Optic Harness capa- Consult your local Tyco Electronics Sales Representative for additional options. bilities. Please consult your * Contact Tyco Electronics for availability. LuxCis is a trademark of Radiall, local Tyco Electronics Sales S.A. - Page 21 – the smallest expanded Mini-Expanded Beam, Key A Assembly Capabilities beam multi-channel insert in GPRB Tyco Electronics has exten- 1445163-1 the industry a Tyco Electronics sive Rugged Optic Harness exclusive. capabilities. Please consult your local Tyco Electronics Sales Representative for assistance.
-
Page 22: Contacts & Application Tools
Straight 1738710-1 0-91067-2 M81969/1-02 termination are available — Straight 1738711-1 1738327-1 M81969/28-02 Consult Tyco Electronics. Catalog 1654763 Dimensions are in millimeters Dimensions are shown for USA: 1-800-522-6752 South America: 55-11-2103-6000 Revised 6-06 and inches unless otherwise reference purposes only. Canada: 1-905-470-4425 Hong Kong: 852-2735-1628 specified. -
Page 23: Spare Parts & Tools
1918614-1 1918616-1 1828199-1 1.5 - 2.2mm 1918615-1 1918617-1 1828200-1 Consult your local Tyco Electronics Sales Representative for additional options. * Contact Tyco Electronics for availability. Spare Parts and Tools GPRA and GPRB Series Spare Parts Part Number Description To Be Used With... -
Page 24: Emi Backshells & Strain Reliefs
General Purpose Rectangular (GPR) Connectors EMI Backshells and Strain Reliefs GPRB Series Part Number Description Used With 1738310-1 Straight strain relief GPRB1 1738311-1 45° strain relief GPRB1 1738312-1 Straight backshell GPRB1 1738313-1 Straight strain relief GPRB2 1738314-1 Backshell for shielded termination GPRB2 1738315-1 Backshell for screened twisted-pair cables... -
Page 25: Gallery Insert (Gain) Connectors
General Purpose Rectangular (GPR) Connectors Galley Insert (GAIN) Connectors 75.90 Max. 16.70±0.15 (2.988 Max.) (0.657±.006) 18.90 Max. (0.744 Max.) 7.70 (0.303) 96.60 Max. (3.803 Max.) 5.05±0.10 88.00 Max. (0.199±.004) (3.464 Max.) Receptacle Shell, Front Panel Mount, with Guide Socket GPRB2 1811119-1 76.2 min. -
Page 26: Custom Solutions & In Development Products
Low weight, Skydrol® resistant composite shells have been developed. Solutions for Data Bus Tyco Electronics is at the leading edge of providing solutions for high-speed data transmission such as size 8 quadrax contacts for Ethernet. Connectors for Size 3 Coaxial Contacts A high-reliability design for high specification RF requirements. - Page 27 +39-011-4031116 Fax: +34-93-200-3779 (Technical Support) Phone: +49-6251-133-1999 Lithuania – Vilnius Fax: +49-6251-133-1988 Sweden – Upplands Väsby Phone: +370-5-2131-402 Phone: +46-8-50-72-50-00 Fax: +370-5-2131-403 Fax: +46-8-50-72-50-01 Germany – Langen Phone: +49-6103-709-0 Fax: +49-6103-709-1223 1654763–1.5M–SK/GIC–FP–6-06 Tyco Electronics Corporation Printed in the U.S.A. www.tycoelectronics.com...
- Page 28 Tyco Electronics Corporation Harrisburg, Pennsylvania www.tycoelectronics.com 1654763 Revised 06-2006 2.5M FP...
