Sperry instruments SMART meter Operating Instructions Manual page 6

6.3 Polarity Indication
1. The meter displays "-" for negative values, positive is implied.
6.4. Overload indication
1. When the input exceeds the measuring range "OL" or "-OL" is displayed on the LCD screen.
7. Smart Device & Application
• The Sperry SMARTmeter has the ability to be connected to your smart device via a Bluetooth connection.
• While the connection is established the meter will continually transmit data to your smart device.
• The measurement data will be shown in the "Measurement Display Area" of your smart device.
7.1 Interfaces and buttons
Measurement Display Area
7.2 Download the Application
1. Using either App Store® for Apple® or Google Play™ store for Android™ platforms,
search for "Sperry Smart Meter" and select "GET" for Apple® or "Install" for Android™ .
2. Once the application has finished installing the SperrySmartMeter app icon
will appear on your device.
7.3 Opening the Application
1. Locate the Sperry SMARTmeter app.
2. Touch the icon to open.
7.4 Connecting Your Smart Device
1. Make sure that your smart device has Bluetooth enabled.
2. Turn on the SMARTmeter by pressing and releasing the SELECT button.
3. Open the SMARTmeter app on your smart device.
4. Touch the "Connect" button on your smart device.
5. Press the "Scan" button on your smart device.
6. A list of devices will appear. Select the device "SDMM10000"
7. The devices are now connected. The Bluetooth symbol
SMARTmeter and your smart device.
Place your finger near the vertical
centerline of the display and swipe
left to view the Data Chart, swipe
right to view the Data Table.
6
should appear on both the
