PARTS LIST

ITEM QUANTITY REFERENCE-DESCRIPTION
Required Circuit Components:
1 1 CIN1
2 2 CIN13, CIN18
3 2 COUT1, COUT5
4 2 COUT20, COUT21
5 2 R8
6 2 R18, R19
7 4 R30, R31, R32, R33
8 1 R34
9 1 R35
10 1 U5
11 3 C12, C52, C61
12 1 R1
13 1 R2
14 1 R3
15 1 R4
16 1 R12
17 1 R14
18 1 R26
19 1 R29
20 2 U1, U2
Additional Demo Board Circuit Components:
1 2 C14, C38
2 1 C16
3 1 C60
4 1 D1
5 1 R7
6 1 Q14
7 1 R10
8 2 R20
9 3 R11, R16, R17
10
11 0 CIN2, CIN3
12 0 CIN14, CIN19, CIN21, CIN23
13 0 COUT2, COUT3, COUT6
14 0 COUT4, COUT7, COUT11
15 COUT15
16 0 COUT10, COUT14
17 0 COUT19
18 0 COUT23, COUT26, COUT27
DEMO MANUAL DC1668A-A
DESCRIPTION
Cap, 150µF 20% 35V Alum
Cap, 1210 22µF 20% 25V X5R
Cap, 1812 100µF 20% 6.3V X5R
Cap, 470µF 20% 4V POSCAP
Res, 0603 0Ω Jumper
Res, 0603 10Ω 5% 1/10W
Res, 0603 100Ω 5% 1/10W
Res, 0603 100k 5% 1/10W
Res, 0805 0Ω Jumper
IC, LTC6902CMS
Cap, 0603 47pF 10% 50V NP0
Res, 0603 15k 1% 1/10W
Res, 0603 20k 1% 1/10W
Res, 0603 9.53k 1% 1/10W
Res, 0603 6.65k 1% 1/10W
Res, 0603 45.3k 1% 1/10W
Res, 0603 30.1k 1% 1/10W
Res, 0603 0Ω Jumper
Res, 0603 402k 1% 1/10W
IC, µModule Regulator
Cap, 0603 0.1µF 20% 16V X7R
Cap, 0603 1µF 20% 10V X5R
Cap, 0603 1000pF 10% 50V NP0
Diode, Zener 350mW
Res, 0805 2k 5% 1/10W
XSTR, SUD50N03-10CP MOSFET
Res, 0603 10k 5% 1/10W
Res, 0603 0Ω Jumper
Res, 2512 0.015Ω 1% 1W
Cap, 1206 10µF 20% 35V X5R Option
Cap, 1210 22µF 20% 25V X5R Option
Cap, 1812 100µF 20% 6.3V X5R Option
Cap, 1812 Option
Cap, 1812 100µF 20% 6.3V X5R Option
Cap, 1206 Option
Cap, 470µF 20% 4V POSCAP Option
MANUFACTURER'S PART NUMBER
Sanyo 35MV150WXV
AVX 12103D226MAT2A
TDK C4532X5R0J107MZ
Sanyo POSCAP 4TPF470ML
Vishay CRCW06030000Z0EA
AAC CR16-100JM
KOA RK73B1JTTD101J
Vishay CRCW0603100KJNEA
Vishay CRCW08050000Z0EA
Linear Technology LTC6902CMS
AVX 06035A470KAT
Vishay CRCW060315K0FKEA
Vishay CRCW060320K0FKEA
Vishay CRCW06034K53FKEA
Vishay CRCW06036K65FKEA
Vishay CRCW060345K3FKEA
Vishay CRCW060330K1FKEA
Vishay CRCW06030000Z0EA
Panasonic ERJ-3EKF4023
Linear Technology LTM4627EV
Taiyo Yuden EMK107BJ104MA-T
Taiyo Yuden LMK107BJ105MA-T
AVX 06035A102KAT2A
Diodes Inc. MMBZ5227B
AAC CR10-202JM
Siliconix SUD50N03-10CP
AAC CR16-103JM
Vishay CRCW06030000Z0EA
Panasonic ERJM1WSF15MU
Taiyo Yuden GMK316BJ106ML-T Option
AVX 12103D226MAT2A Option
TDK C4532X5R0J107MZ Option
Taiyo Yuden JMK432BJ107MU-T Option
TDK C4532X5R0J107MZ Option
Taiyo Yuden EMK316BJ475ML-T Option
Sanyo Poscap 4TPF470ML Option
