  • Page 1 © Copyright 1996. Black Box Corporation. All rights reserved. 1000 Park Drive • Lawrence, PA 15055-1018 • 724-746-5500 • Fax 724-746-0746...
  • Page 2 Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500) SUPPORT FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746 INFORMATION Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018 Web site: www.blackbox.com • E-mail: info@blackbox.com...
  • Page 3 SERVMASTER TRADEMARKS USED IN THIS MANUAL AT, IBM, OS/2, PS/2, and XGA are registered trademarks of International Business Machines Corporation. Microsoft and Windows are registered trademarks of Microsoft Corporation. Any trademarks mentioned in this manual are acknowledged to be the property of the...
  • Page 4 FCC STATEMENT FEDERAL COMMUNICATIONS COMMISSION CANADIAN DEPARTMENT OF COMMUNICATIONS RADIO FREQUENCY INTERFERENCE STATEMENTS This equipment generates, uses, and can radiate radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer’s instructions, may cause interference to radio communication. It has been tested and found to comply with the limits for a Class A computing device in accordance with the specifications in Subpart J of Part 15 of FCC rules, which are designed to provide reasonable protection against...
  • Page 5 SERVMASTER NORMAS OFICIALES MEXICANAS (NOM) ELECTRICAL SAFETY STATEMENT INSTRUCCIONES DE SEGURIDAD 1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el aparato eléctrico sea operado. 2. Las instrucciones de seguridad y operación deberán ser guardadas para referencia futura.
  • Page 6 NOM STATEMENT 11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo del tipo descrito en el instructivo de operación, o como se indique en el aparato. 12. Precaución debe ser tomada de tal manera que la tierra fisica y la polarización del equipo no sea eliminada.

  • Page 7: Table Of Contents

    SERVMASTER Contents 1. Specifications.....................8 2. Introduction ......................9 2.1 Description ....................9 2.2 Features.......................9 2.3 Package Contents ..................10 2.4 Cable Requirements.................11 2.5 Location ....................11 3. Quick Setup .....................16 4. Installation.......................17 4.1 Step 1: Connecting the Monitor, Keyboard, and Mouse .......17 4.2 Step 2: Connecting the CPU..............17 4.3 Step 3: Connecting the Bus ..............18...
  • Page 8 CONTENTS 5.17 Reset Command..................29 5.18 XGA Video, Model 9515, 9517, and 9518 Monitors ......30 5.19 Video Distance Capability...............30 5.20 Power Interruption to the ServMaster ...........31 6. Keyboard Command Summary ..............32 7. Troubleshooting .....................37 7.1 Problems ....................37 7.2 Calling Your Supplier................41 7.3 Shipping and Packaging ................41...

  • Page 9: Specifications

    SERVMASTER 1. Specifications (3) LEDs, one each of Power (green), Status Indicators (yellow), and Send (yellow) Chassis Fully shielded, black painted steel Controls Power on/off switch 13W3 Female Bus In/Out Connectors CPU/Keyboard- Monitor-Mouse Connectors DB25 female 32 to 122°F (0 to 50°C)

  • Page 10: Introduction

    CHAPTER 2: Introduction 2. Introduction 2.1 Description Designed for plug-and-play operation, your ServMaster will organize your multiple-computer applications. Because ServMaster lets you use several keyboards, monitors, and mice to access a number of computers, you can significantly reduce your equipment overhead and end keyboard and monitor clutter.

  • Page 11: Package Contents

    • Available in 117-VAC (SW990A) or 230-VAC (SW990AE) models. 2.3 Package Contents Your ServMaster package includes the ServMaster (SW990A or SW990AE), a power transformer (SW991), and this manual. Cables are ordered separately (see Appendix E).

  • Page 12: Cable Requirements

    CHAPTER 2: Introduction 2.4 Cable Requirements ServMaster connects to a CPU with a CPU adapter cable and to the monitor, keyboard, and mouse with a Keyboard-Monitor-Mouse adapter cable. If you want to build your own cables, refer to the information in Appendices A, B, and C.
  • Page 13 Send LED Status LED CPU Connector Power LED Address Selector DIP Switches Figure 2-1. The ServMaster Front Panel. Table 2-1. The Front Panel Address Determines the port number of the CPU on the unit. Address 0 is reserved for diagnostics. Address 255 is reserved for security configuration.
  • Page 14 CHAPTER 2: Introduction Table 2-1 (continued). The Front Panel Send LED When lit, video is being sent over the coax bus. One or more monitors may be receiving the video. Keyboard-Monitor-Mouse Keyboard, monitor, and mouse are connected at this port using a Keyboard- Monitor-Mouse adapter cable.
  • Page 15 BUS OUT BUS IN Power Switch Bus In/Bus Out Connector RS-232 Connector Figure 2-2. The ServMaster Rear Panel. Table 2-2. The Rear Panel Bus In/Bus Out Bus cable to next unit or terminator is connected here. Terminator or bus cable may be connected to either Bus In or Bus Out.
  • Page 16 CHAPTER 2: Introduction Table 2-2 (continued). The Rear Panel Power The power transformer (SW991) connects here. This is not a keyboard input. Power transformers are available for U.S. or International use. Input voltage is 17 VAC with center tap.

  • Page 17: Quick Setup

    SERVMASTER 3. Quick Setup The following diagrams offer basic examples of how to connect your CPUs, keyboard, monitor, and mouse and the ServMasters to one another. Connectors will vary depending upon the types of equipment being installed. ServMaster CPU Adapter...

  • Page 18: Installation

    A CPU adapter cable (EHN048, EHN049, EHN051) connects your computer to the ServMaster. CPU adapter cables are available where you purchased your ServMaster. If you prefer to build your own cable, pinout information is shown in Appendices A and B.

  • Page 19: Step 3: Connecting The Bus

    4.4 Step 4: Powering Up the System Plug the power transformer’s (SW991) power jack into the power plug located on the back of the ServMaster unit. Plug the transformer into a power strip or wall outlet. Push the On/Off switch on the back of the ServMaster to power-up.

  • Page 20: Step 5: Testing The Installation

    CHAPTER 4: Installation 4.5 Step 5: Testing the Installation Your ServMaster is now ready for operation using its default settings. To take full advantage of the ServMaster features, refer to Chapter 5. Chapter 5 gives detailed information about each of the ServMaster commands, describing its application and giving the keyboard command sequence.
  • Page 21 SERVMASTER NOTE Before entering any ServMaster keyboard command, you must press and release the left Control Key. This activates ServMaster to look for commands from the keyboard. You then have two seconds in which to start entering a valid command.

  • Page 22: Operation

    CHAPTER 5: Operation 5. Operation ServMaster is simple to operate. Port selection and function commands are entered from the keyboard. This chapter describes each ServMaster function. See Chapter 6 for an easy-to-read table of keyboard commands, and Appendix C for a list of the factory-default settings.

  • Page 23: Going To The Next Highest Or Lowest Port

    (such as 01) or enter the single-digit number and press [Enter]. If you enter only one digit, and do not follow it with [Enter], ServMaster will wait two seconds for you to enter another digit. If no additional number is entered, ServMaster will switch immediately to the single-digit port.

  • Page 24: Access-Level Command

    CHAPTER 5: Operation If the timeout is set for zero, this is an instant timeout. Two keyboards each set for a zero timeout and connected to the same CPU will appear to both be connected to the CPU. If the timeout is set for 255, this is an infinite timeout. A CPU will not be released, until another port is switched to or the timeout is changed, from the keyboard with the infinite timeout.

  • Page 25: Power-Up Port Command

    SERVMASTER Table 5-1. Access-Level Values Access Level Local Only Disconnect On Change Disable Disable Disable Enable Enable Disable Enable Enable 5.5 Power-Up Port Command This setting is intended to provide a port to which you will connect to upon power-up of a unit. If local only is enabled (see Section 5.4), this is ignored and you will be switched to the CPU on the unit.

  • Page 26: Scan Mode Commands

    5.7 Scan Mode Commands To enable scanning from the keyboard, press and release the left Control Key, then type “S”. ServMaster will begin scanning sequentially from its current port through the remaining ports up to the maximum scan port and begin again at the minimum scan port.

  • Page 27: Screen Blanking Command

    Follow with the Keep command (left Control, K) to save the new setting in the unit’s non-volatile memory. When in the Screen Blank state, all ServMaster Select LEDs will be off. To restore the video screen, press any key or move the mouse. To disable the screen blank feature, press and release the left Control Key, type “V”, enter...

  • Page 28: Typematic Value Command

    CHAPTER 5: Operation 5.12 Typematic Value Command ServMaster can be configured to control the keyboard typematic rate and delay. This setting is used to adjust the user preference of the way the keyboard acts when holding a key down to repeat the key, such as when moving a cursor across a line.

  • Page 29: Maximum Ports Command

    ServMaster and not CPUs on other units. The port number of the ServMaster CPUs from this local keyboard now starts at 1 and ends at the value set by Maximum port. From other units which are not set to local only, the address remains the same.

  • Page 30: Null Command

    CPU which has not enabled the mouse. This may be the case if the ServMaster was not connected or powered off after a CPU was booted up. To issue the command, press and release the left Control Key, then type “R”.

  • Page 31: Xga Video, Model 9515, 9517, And 9518 Monitors

    SERVMASTER 5.18 XGA Video, Model 9515, 9517, and 9518 Monitors Many models of IBM PS/2 come with XGA and XGA-2 video. You should have ordered the Universal CPU cable for your CPU (call your supplier). If this cable is not used, you may be unable to switch to high-resolution video. If you wish to use XGA monochrome, you must also order a Universal CPU cable.

  • Page 32: Power Interruption To The Servmaster

    5.20 Power Interruption to the ServMaster Certain keyboards are sensitive to rapid cycling of the power. Since power to the keyboard is provided from the ServMaster, you should not interrupt power to the ServMaster for less than three seconds. The ServMaster is...

  • Page 33: Keyboard Command Summary

    The [Ctrl] character is not passed through to the CPU when it is pressed and released. The command characters and command operands are absorbed by the ServMaster and not sent to the CPU. All non-switching commands which require a numeric operand must use the [Enter] key to complete the command.
  • Page 34 Scan time interval [Ctrl]Txx[Enter] where Sets the time, in seconds, that the “xx” is time in seconds ServMaster will pause at each from 1 to 15 seconds port when scanning. Note: Follow with the Keep command. Minimum scan port [Ctrl]<xxx[Enter] where...
  • Page 35 SERVMASTER Table 6-1 (continued). Keyboard Command Summary Command Key Sequence Description Maximum scan port [Ctrl]>xxx[Enter] where Sets port number of the highest “xxx” is port number port for scanning. When scanning and maximum scan is reached, the next port will be minimum scan.
  • Page 36 Used to re-synchronize PS/2 mouse that has gotten out of sync. Identify ROM version [Ctrl]I Identifies ROM version. CPU must be at some sort of command prompt to receive value. Keep settings [Ctrl]K Tells ServMaster to save custom settings of various commands.
  • Page 37 [Ctrl]Axxx[Enter] where Sets power-on keyboard “xxx” is a number from typematic action, which is 0 to 127 indicating controlled by the ServMaster. This keyboard typematic can be used to adjust the value keystroke rate and delay to the user-preferred setting. See Tables 5-2 and 5-3 for how the typematic value is determined.

  • Page 38: Troubleshooting

    The cable may be defective. Try using cable from another CPU. If the problem goes away, the original cable is defective. d. A port on the ServMaster may be defective. Try using another port on the ServMaster. If the problem goes away, the original port is defective.
  • Page 39 9.01 driver is the best one available. 3. Can’t switch ports from the keyboard. a. Power to the ServMaster was removed for less than three seconds, possibly causing the keyboard to lock up. Disconnect the keyboard and plug it back in.
  • Page 40 Microsoft revision 9.01 driver. 6. The mouse does not move. a. ServMaster was not connected or turned off after the CPU booted, or an application using the mouse was run. Exit and re- enter the application using the mouse or issue the reset command.
  • Page 41 The cable is defective. Try using cable from another CPU. If the problem goes away, the original cable is defective. d. The port on the ServMaster is defective. Try using the same port on another ServMaster. If the problem goes away, the port on the original unit is defective.

  • Page 42: Calling Your Supplier

    If you need to transport or ship your ServMaster: • Package it carefully. We recommend that you use the original container. • If you are shipping the ServMaster for repair, make sure you include everything that came with the ServMaster package. Before you ship,...

  • Page 43: Appendix A. Cable Pinout Information

    A.1 Pin-to-Pin Wiring: Keyboard-Monitor-Mouse Adapter Keyboard Serial Mouse Monitor DB-25M Mouse/Keyboard/Monitor Adapter Cable PS/2 Keyboard with MiniDIN-6M ServMaster DB25M Keyboard MiniDIN-6F Signals Digital Ground Keyboard Clock Keyboard Data PC Keyboard with DIN-5M ServMaster DB25M Keyboard DIN-5M Signals...
  • Page 44 APPENDIX A: Cable Pinout Information PS/2 Mouse with MiniDIN-6M ServMaster DB25M Keyboard MiniDIN-6F Signals Digital Ground Mouse Clock Mouse Data Serial Mouse with DB9F ServMaster DB25M Mouse DB9M Signals Digital Ground TxD* DTR* Serial Mouse with DB25F ServMaster DB25M Mouse DB25M...

  • Page 45: Pin-To-Pin Wiring: Cpu Adapter

    A.2 Pin-to-Pin Wiring: CPU Adapter Serial Mouse Keyboard Video DB-25M Card CPU Adapter Cable PS/2 Keyboard Port with MiniDIN-6F ServMaster DB25M Keyboard MiniDIN-6M Signals Digital Ground Keyboard Clock Keyboard Data CPU Keyboard Port with DIN-5F ServMaster DB25M Keyboard DIN-5M Signals...
  • Page 46 APPENDIX A: Cable Pinout Information Serial Mouse Port with DB9M ServMaster DB25M Mouse DB9M Signals Digital Ground Serial Mouse Port with DB25M ServMaster DB25M Mouse DB25F Signals Digital Ground VGA Video Port with HD-15F ServMaster DB25M Monitor HD-15M Signals 1, 2, 3...

  • Page 47: Appendix B. Cpu/Keyboard-Monitor-Mouse Pinout

    SERVMASTER Appendix B. CPU/Keyboard-Monitor- Mouse Pinout 25 24 23 22 21 20 19 17 16 Pinouts for ServMaster DB25 Female Connectors Numbered Keyboard-Monitor- Pins CPU Ports Mouse Port Description Ground Ground Analog Ground Ground Ground Analog Ground Ground Ground Analog Ground...
  • Page 48 APPENDIX A: Cable Pinout Information Pinouts for ServMaster DB25 Female Connectors (continued) Numbered Keyboard-Monitor- Pins CPU Ports Mouse Port Description Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Ground Ground Digital Ground Ground...

  • Page 49: Appendix C. Factory-Default Settings

    SERVMASTER Appendix C. Factory-Default Settings Setting Default Scan enable Scan Time Interval 5 seconds Scan minimum port 1 (local) Scan maximum port 16 (local) Power-up port 1 (local) Number of ports 16, or 1 when address=255 Access level 0 (local only and disconnect on change disabled)

  • Page 50: Appendix D. Dip-Switch Description

    APPENDIX D: DIP-Switch Description Appendix D. DIP-Switch Description DIP-Switch Position 128 64 DIP-Switch Value A unit’s address is determined from the settings of the DIP switch at power- up. The DIP switch forms a standard binary number with UP being a “one” and DOWN being a “zero.”...

  • Page 51: Appendix E. Cables

    Lengths available (in feet) are 5, 10, 20, 25, 50, 75, and 100. Lengths greater than 100 feet are available through special order. Product Code Product Name EHN275-0005 ServMaster Bus Cable (5 ft.) EHN275-0010 ServMaster Bus Cable (10 ft.) EHN275-0020 ServMaster Bus Cable (20 ft.) EHN275-0025 ServMaster Bus Cable (25 ft.)
