Welcome to the ServSwitch™ Family!
Thank you for purchasing a BLACK BOX
business, and we think you'll appreciate the many ways that your new ServSelect IP
will save you money, time, and effort.
That's because our ServSwitch™ family is all about breaking away from the
traditional, expensive model of computer management. You know, the one-size-fits-
all-even-if-it-doesn't model that says, "One computer gets one user station, no more,
no less." Why not a single user station (monitor, keyboard, and mouse) for multiple
computers — even computers of different platforms? Why not a pair of user
stations, each of which can control multiple computers? Why not multiple user
stations for the same computer?
With our ServSwitch products, there's no reason why not. We carry a broad line of
robust solutions for all these applications. Do you have just two PCs, and need an
economical alternative to keeping two monitors, keyboards, and mice on your desk?
Or do you need to share dozens of computers, including a mix of IBM
®
®
®
RS/6000
, Apple
Macintosh
, Sun Microsystems
multiple users with different access levels? Does your switch have to sit solidly on a
work table and use regular everyday cables? Or does it have to be mounted in an
equipment rack and use convenient many-to-one cables? No matter how large or
small your setup is, no matter how simple or how complex, we're confident we have
a ServSwitch system that's just right for you.
The ServSwitch family from BLACK BOX — the one-stop answer for all your
KVM switching needs!
This manual will tell you all about your new ServSelect IP, including how to install,
operate, and troubleshoot it. For an introduction to the ServSelect IP, see Chapter 2.
The ServSelect IP product codes covered in this manual are:
KV120A
This manual also includes information about the ServSelect IP software and the
Server Access Modules, which have their own manuals or installation guides:
KV123A
And this manual also includes information about the ServSwitch Multi Z8 and
ServSelect II switch:
SERVSWITCH FAMILY
®
ServSelect IP™! We appreciate your
®
, and SGI™ compatibles among
*
KV120E
KV121A
KV121E
KV125A
KV126A
KV127A
KV158A
KV2016A
®
PC,
1
