Reference Designator
R40
R41
R44, R45
R59
REFIN, RFOUT+, RFOUT−
U1
U2, U10
U3, U4, U5
U6
U7
U8
USB
VCO_I/O, VTUNE, VVCO
VSUPPLY_5V5
Y1 (ALT)
Y2
Y3

RELATED LINKS

Resource Description
ADF4151 Product Page, Fractional-N/Integer-N PLL Synthesizer
ADP150 Product Page, Ultralow Noise, 150 mA CMOS Linear Regulator
ADP3334 Product Page, High Accuracy Low IQ, 500 mA anyCAP® Adjustable Low Dropout Regulator
Value Description
140 kΩ SMD resistor
78.7 kΩ SMD resistor
100 kΩ SMD resistor
120 Ω SMD resistor
End-launch 50 Ω SMA jack
PLL
3.3 V linear regulator
Adjustable LDO regulator
USB microcontroller
2
64 k I C serial EEPROM
50 MHz to 6 GHz RF/IF gain block
USB Mini-B connector (USB-OTG)
End-launch 50 Ω SMA jack
Red 4 mm banana socket
25 MHz SMD temperature compensated crystal
oscillator
24 MHz SMD crystal
1700 MHz to VCO
1800 MHz
Rev. A | Page 22 of 24
Evaluation Board User Guide
Manufacturer/Part Number
Multicomp MC 0.063W 0603 1% 140K
Multicomp MC 0.063W 0603 1% 78K7
Multicomp MC 0.063W 0603 100K
Multicomp MC 0.063W 0603 1% 120R
Emerson Network 142-0701-851
Analog Devices ADF4151
Analog Devices ADP150AUJZ-3.3
Analog Devices ADP3334ARMZ
Cypress Semiconductor
CY7C68013A-56LFXC
Microchip Technology 24LC64-ISN
Analog Devices ADF4151ACPZ
Molex 54819-0578
Emerson Network 142-0701-851
Deltron 571-0500-01
Rakon TXO225B
ECS International ECS-240-12-20A-TR
Mini-Circuits ROS-1800+
