Chapter 2: Jumpers and Connectors

LAN3 and USB 3.1 Ports

Connector type: RJ45 port with LEDs
Dual USB 3.1 port
Connector location: LAN3A (USB) and LAN3B (LAN)
ACT LINK
27 20
18 14
10 13
9 5
1 4
Pin Definition
1 5VUSB3
3 USB2P_1
5 S_USB31_RXN1
7 GND
9 USB31_TXP1
11 USB2N_7
13 GND
15 S_USB31_RXP2
Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved.
Act Status
Flashing Yellow Data activity
Off No activity
Link Status
Steady Green 1G network link
Steady Orange 100Mbps network link
Off No link
Pin Definition
2 USB2N_1
4 GND
6 S_USB31_RXP1
8 USB31_TXN1
10 5VUSB3
12 USB2P_7
14 S_USB31_RXN2
16 GND
Pin Definition
17 USB31_TXN2
19 LAN2TCT
21 LAN2MDI0N
23 LAN2MDI1N
25 LAN2MDI2N
27 LAN2MDI3N
29 LAN2ACTCON
31 LAN2100CON
35
Pin Definition
18 USB31_TXP2
20 LAN2MDI0P
22 LAN2MDI1P
24 LAN2MDI2P
26 LAN2MDI3P
28 GND
30 LAN2LEDACTN
32 LAN2LINK1GN
