MELSEC iQ-R MELSECNET/H Network Module
User's Manual (Startup)
-RJ71LP21-25

Advertisement

Table of Contents
loading

Related Manuals for Mitsubishi Electric MELSEC iQ-R RJ71LP21-25

Summary of Contents for Mitsubishi Electric MELSEC iQ-R RJ71LP21-25

  • Page 1 MELSEC iQ-R MELSECNET/H Network Module User's Manual (Startup) -RJ71LP21-25...

  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS (Read these precautions before using this product.) Before using this product, please read this manual and the relevant manuals carefully and pay full attention to safety to handle the product correctly. The precautions given in this manual are concerned with this product only. For the safety precautions of the programmable controller system, refer to the MELSEC iQ-R Module Configuration Manual.
  • Page 4 [Design Precautions] WARNING ● Configure safety circuits external to the programmable controller to ensure that the entire system operates safely even when a fault occurs in the external power supply or the programmable controller. Failure to do so may result in an accident due to an incorrect output or malfunction. (1) Emergency stop circuits, protection circuits, and protective interlock circuits for conflicting operations (such as forward/reverse rotations or upper/lower limit positioning) must be configured external to the programmable controller.
  • Page 5 [Design Precautions] WARNING ● Do not write any data to the "system area" and "write-protect area" of the buffer memory in the module. Also, do not use any "use prohibited" signals as an output signal from the CPU module to each module.
  • Page 6 [Installation Precautions] WARNING ● Shut off the external power supply (all phases) used in the system before mounting or removing the module. Failure to do so may result in electric shock or cause the module to fail or malfunction. [Installation Precautions] CAUTION ●...
  • Page 7 [Wiring Precautions] CAUTION ● Individually ground the FG and LG terminals of the programmable controller with a ground resistance of 100 ohms or less. Failure to do so may result in electric shock or malfunction. ● Use applicable solderless terminals and tighten them within the specified torque range. If any spade solderless terminal is used, it may be disconnected when the terminal screw comes loose, resulting in failure.
  • Page 8 [Wiring Precautions] CAUTION ● Programmable controllers must be installed in control panels. Connect the main power supply to the power supply module in the control panel through a relay terminal block. Wiring and replacement of a power supply module must be performed by qualified maintenance personnel with knowledge of protection against electric shock.
  • Page 9 [Startup and Maintenance Precautions] CAUTION ● Shut off the external power supply (all phases) used in the system before mounting or removing the module. Failure to do so may cause the module to fail or malfunction. ● Tighten the screws within the specified torque range. Undertightening can cause drop of the component or wire, short circuit, or malfunction.
  • Page 10 [Disposal Precautions] CAUTION ● When disposing of this product, treat it as industrial waste. [Transportation Precautions] CAUTION ● The halogens (such as fluorine, chlorine, bromine, and iodine), which are contained in a fumigant used for disinfection and pest control of wood packaging materials, may cause failure of the product. Prevent the entry of fumigant residues into the product or consider other methods (such as heat treatment) instead of fumigation.

  • Page 11: Conditions Of Use For The Product

    Mitsubishi representative in your region. INTRODUCTION Thank you for purchasing the Mitsubishi Electric MELSEC iQ-R series programmable controllers. This manual describes the procedures, system configuration, and wiring of the relevant products listed below. Before using this product, please read this manual and the relevant manuals carefully and develop familiarity with the functions and performance of the MELSEC iQ-R series programmable controller to handle the product correctly.

  • Page 12: Compliance With Emc And Low Voltage Directives

    COMPLIANCE WITH EMC AND LOW VOLTAGE DIRECTIVES Method of ensuring compliance To ensure that Mitsubishi programmable controllers maintain EMC and Low Voltage Directives when incorporated into other machinery or equipment, certain measures may be necessary. Please refer to one of the following manuals. •...

  • Page 13: Table Of Contents

    CONTENTS SAFETY PRECAUTIONS ..............1 CONDITIONS OF USE FOR THE PRODUCT .

  • Page 14: Relevant Manuals

    • Installation For details, refer to the following.  MELSEC iQ-R Module Configuration Manual e-Manual refers to the Mitsubishi Electric FA electronic book manuals that can be browsed using a dedicated tool. e-Manual has the following features: • Required information can be cross-searched in multiple manuals.

  • Page 15: Terms

    TERMS Unless otherwise specified, this manual uses the following terms. Term Description Baton pass A token to send data over a network Buffer memory Memory in an intelligent function module for storing data such as setting values and monitored values. When integrated into the CPU module, this memory refers to a memory for storing data such as setting values and monitored values of the Ethernet function, and data used for data communication of the multiple CPU system function.

  • Page 16: Generic Terms And Abbreviations

    GENERIC TERMS AND ABBREVIATIONS Unless otherwise specified, this manual uses the following generic terms and abbreviations. Generic term/abbreviation Description Network module A generic term for the following modules: • Ethernet interface module • A module on CC-Link IE TSN (the RJ71GN11-T2 and a module on a remote station) •...

  • Page 17: Chapter 1 Part Names

    PART NAMES This chapter describes the names of each part of the RJ71LP21-25. Name Description RUN LED On: Normal operation Off: Error ( MELSEC iQ-R MELSECNET/H Network Module User's Manual (Application)) ERR LED On or flashing: Error ( MELSEC iQ-R MELSECNET/H Network Module User's Manual (Application)) Off: Normal operation T PASS LED On: Baton pass (state of connecting to the network)
  • Page 18 Dot matrix LED indication Displays the station number set to the RJ71LP21-25 and the status of each test. Module operation mode Display Online mode Displays the station number currently set to the RJ71LP21-25. Debug mode • Control station, normal station: 1 to 64 •...

  • Page 19: Chapter 2 Specifications

    SPECIFICATIONS Performance Specifications The following table lists the performance specifications of the RJ71LP21-25. Item Description Maximum number of 16384 points (MELSECNET/10 mode: 8192 points) link points per 16384 points (MELSECNET/10 mode: 8192 points) network 8192 points 8192 points Maximum number of •...

  • Page 20: Cable Specifications

    Cable Specifications The following table lists the specifications of optical fiber cables. The types of optical fiber cables that can be used vary depending on the station-to-station distance. Type Station-to-station distance Applicable connector 25Mbps 10Mbps SI optical fiber cable Type L 200m 500m F06/F08 equivalent (JIS...

  • Page 21: Chapter 3 Function List

    FUNCTION LIST This chapter describes the functions of the RJ71LP21-25. For details on the functions, refer to the following.  MELSEC iQ-R MELSECNET/H Network Module User's Manual (Application) Cyclic transmission function : Available, : Not available Function name Description Availability Control Normal station...
  • Page 22 RAS function : Available, : Not available Function name Description Availability Control Normal station station   Automatic return Automatically returns the station disconnected from the network due to a data link error to the network when it recovers and restarts data link.
  • Page 23 Redundant system function : Available, : Not available Function name Description Availability Control Normal station station   Redundant system function Consists of a control system and standby system. When an error occurs in the control system, the standby system is switched to the new control system and cyclic transmission continues.

  • Page 24: Chapter 4 Procedures Before Operation

    PROCEDURES BEFORE OPERATION This chapter describes the procedures before operation. Network construction Configure the system and set the parameters which are required for start-up. • Wiring ( Page 26 WIRING) • Parameter setting ( MELSEC iQ-R MELSECNET/H Network Module User's Manual (Application)) Network diagnostics Using MELSECNET diagnostics, check if the cables are connected properly and communication is performed normally with the configured parameters.
  • Page 25 MEMO 4 PROCEDURES BEFORE OPERATION...

  • Page 26: Chapter 5 System Configuration

    SYSTEM CONFIGURATION This chapter describes the system configuration of MELSECNET/H network. MELSECNET/H Network Configuration Single-network system A system in which the control station and normal stations are connected with optical fiber cables. A total of 64 stations can be connected: one control station and 63 normal stations. A station with any station number can be set as the control station.
  • Page 27 Multi-network system A system in which multiple networks are connected at a relay station. A maximum of 239 networks can be connected regardless of the network type, such as Ethernet, CC-Link IE TSN, CC-Link IE Controller Network, and CC-Link IE Field Network.

  • Page 28: Chapter 6 Wiring

    WIRING This chapter describes the wiring when MELSECNET/H network is used. Wiring Methods This section describes connection and disconnection of the optical fiber cable. The RJ71LP21-25 has IN connector and OUT connector. Connect the IN connector of own station to OUT connector of another station and OUT connector of own station to IN connector of another station.
  • Page 29 Disconnecting the cable Turn the power off. Press the side buttons that engage the locking mechanism in the direction of the arrows to pull the plug Plug out. For storage, attach the covers that were attached to both the plug and the jack before connecting them. Cover Precautions •...

  • Page 30: Wiring Products

    Wiring Products Optical fiber cables with connectors (optical fiber cables for MELSEC) are available from Mitsubishi Electric System & Service Co., Ltd. (Catalogs for the optical fiber cables are also available.) In addition, installation work is also available for your preference.

  • Page 31: Chapter 7 Communication Examples

    COMMUNICATION EXAMPLES Cyclic Transmission Program This section describes the procedure for creating a program using cyclic transmission. System configuration example The following system configuration is used to explain communication between the control station and normal station. System configuration Item Model Control station (station No.1) Power supply module R61P...
  • Page 32 Link device assignment ■LB and LW assignment No.1: control station, No.2: normal station. CPU module No.1 No.2 CPU module Label Label LB0000 to LB00FF LB0000 to LB00FF LB0000 to LB00FF LB0000 to LB00FF LB0100 to LB01FF LB0100 to LB01FF LW0000 to LW00FF LW0000 to LW00FF LW0000 to LW00FF LW0000 to LW00FF...

  • Page 33: Setting In The Control Station

    Setting in the control station Connect the engineering tool to the CPU module on the control station and set the parameters. Set the CPU module as follows. [Project]  [New] Click the [Setting Change] button and set "Use" for "Module Label". Set the RJ71LP21-25 as follows.
  • Page 34 Click the [OK] button to add the module labels of the RJ71LP21-25. Set the items in "Required Settings" as follows. [Navigation window]  [Parameter]  [Module Information]  [RJ71LP21-25]  [Required Settings] Set the network range assignment as follows and click the [Apply] button. [Required Settings] ...
  • Page 35 Set the items in "Basic Settings" as follows. [Navigation window]  [Parameter]  [Module Information]  [RJ71LP21-25]  [Basic Settings] Set the link refresh settings as follows and click the [Apply] button. [Basic Settings]  [Link Refresh Settings]  [Detailed Setting] Write the set parameters to the CPU module of the control station.

  • Page 36: Setting In The Normal Stations

    Setting in the normal stations Connect the engineering tool to the CPU module on the normal station and set the parameters. Set the CPU module and add a module label of the CPU module. The setting method of the CPU module and addition method of the module label are the same as those of the control station.
  • Page 37 Set the items in "Basic Settings" as follows. [Navigation window]  [Parameter]  [Module Information]  [RJ71LP21-25]  [Basic Settings] Set the link refresh settings as follows and click the [Apply] button. [Basic Settings]  [Link Refresh Settings]  [Detailed Setting] Write the set parameters to the CPU module of the control station.

  • Page 38: Checking The Network Status

    Checking the network status Once parameters are set for the control station and normal station, the MELSECNET diagnostics of the engineering tool can be used to check whether data link is normally operating. Connect the engineering tool to the CPU module on the control station. Start MELSECNET diagnostics.

  • Page 39: Program Example

    Program example This section describes program examples. Program example of cyclic transmission The values in D0 to D3 of the control station (station No.1) are sent to D100 to D103 of the normal station (station No.2) through cyclic transmission. When creating a program, configure an interlock using 'Data link error status of own station' (SB0049) and 'Data link status of each station' (SW0074 to SW0077).
  • Page 40 (41)When 'bSendRequest' (M100) is turned on, the contents of 'uOutputData' (D0 to D3) is stored in 'uData' (W0 to W3). When data storage is completed, 'bHandShake1' (B0) is turned on. (49)When 'bHandShake2' (B100) in the normal station (station No.2) is turned on, 'bHandShake1' (B0) is turned off. 7 COMMUNICATION EXAMPLES 7.1 Cyclic Transmission Program...
  • Page 41 • Normal station (station No.2) Classification Label name Description Device Module label LP21_1.bDetect_DataLinkError Data link error status of own station SB0049 LP21_1.bnSts_CyclicTransmissionError_Station[1] Data link status of each station SW0074.0 (station No.1) Label to be defined Define global labels as shown below: (41)When 'bHandShake1' (B0) is turned on in the control station (station No.1), the contents of 'uData' (W0 to W3) is stored in 'uOutputData' (D100 to D103).

  • Page 42: Transient Transmission Program

    Transient Transmission Program This section describes the procedure for creating a program using transient transmission. System configuration example For details on the system configuration, refer to the following. Page 29 System configuration Setting in the control station For details on how to set parameters for the control station, refer to the following. Page 31 Setting in the control station Setting in the normal stations For details on how to set parameters for the normal stations, refer to the following.
  • Page 43 ■Program example • Control station (station No.1) (23)When bTransientStart is turned on while there is no error in 'Baton pass error status of own station' (SB0047) and 'Baton pass status of each station' (SW0070 to SW0073), the number of resends is set and dedicated instruction GP.READ is executed. (41)When dedicated instruction GP.READ is successfully completed, bSuccessFlg is turned on.

  • Page 44: Appendix

    APPENDIX Appendix 1 External Dimensions This chapter describes the external dimensions of the RJ71LP21-25. 27.8 (Unit: mm) APPX Appendix 1 External Dimensions...
  • Page 45 MEMO APPX Appendix 1 External Dimensions...

  • Page 46: Index

    INDEX ......20 Automatic return ..... . . 19 Constant link scan .
  • Page 47 MEMO...

  • Page 48: Revisions

    Japanese manual number: SH-082201-A This manual confers no industrial property rights or any rights of any other kind, nor does it confer any patent licenses. Mitsubishi Electric Corporation cannot be held responsible for any problems involving industrial property rights which may occur as a result of using the contents noted in this manual.

  • Page 49: Warranty
