MegaPixel IP CamerasSoftware | en
NOTE! DiBos8 automatically scales an image to a 4 (H) x 3 (V)
aspect ratio for display. Always maintain the selected image
area to be displayed at a 4x3 aspect ratio.
PARAMETER
<ip_address>
/image?
<resolution_value>
<x0_value>
<y0_value>
<x1_value>
<y1_value>
<quality_value>
<doublescan_value> Doublescan is the parameter
<port_no>
Table 4.1 HTTP command string parameters
Bosch Security Systems
DESCRIPTION
The IP address of the camera e.g. 192.168.2.75
Image request command
Specifies whether the cam-
era should decimate the
image by the factor of 2 in
each direction
The left hand coordinates of
the requested image window
The top coordinates of the
requested image window
The right hand coordinates of
the requested image window
The bottom coordinates of
the requested image window
The compression quality of
the JPEG image with the
range from 1 to 21
that allows the user to spec-
ify whether the camera
should delay the image out-
put until the new image is
scanned (doublescan=0) or
the image request should be
serviced immediately by out-
putting the content of the
current image in the image
buffer (doublescan=1) (the
image will be displayed faster
on the screen)
The camera sends "ismotion"
to the specified port No. if
motion is detected and
"nomotion" if motion is not
detected.
User Manual
COMMENT
full or half, e.g. res=
half=> an image with
1600x1200 will
become 800x600
default: x0=0
default: y0=0
e.g. x1=1600
e.g. y1=1200
default: quality=12.
21 gives highest quality
e.g. doublescan=0
e.g. port_no=3028
This parameter is
optional.
