10 en | Introduction
–
–
–
–
High performance, with best frame rate live viewing:
–
–
–
–
Monitors, for full resolution live viewing:
–
–
For Setup and verification:
–
2.3

Network switch or router

Using a 100 Mbps network switch or router is recommended.
Simple hubs do not provide collision management and are not
suitable for a multi-camera audio/video system. Suggested
models:
Power-over-Ethernet routers:
–
–
–
–
F.01U.064.422 | V 1.0 | 2007.03
CPU: 3.0 GHz
RAM: 512 MB
Video Card: 1600x1200, 64 MB RAM
Network card: 100 base-T
CPU: Dual CPU or DualCore 3.2 GHz
RAM: 1 GB
Video card: 1920x1200, 128 MB RAM (for NWC-0800 reso-
lution)
Network card: 100 base-T, 2 network cards - one for cam-
eras and one for other network functions
24-inch Wide Aspect Flat Panel LCD Monitor with Height
Adjustable Stand (1920x1200 Resolution)
24 Inch LCD Display (1920 x 1200 resolution)
Standard PC monitors can be used, images are automati-
cally scaled to the correct size.
"Netgear ProSafe 8PT 100Base-TX Switch with PoE
#FS108PNA
10/100Base-TX w/4 PoE 100Base-TX
"Netgear ProSave 16PT 100Base-TX Switch with PoE
#FS116P
10/100Base-TX w/8 PoE 100Base-TX
"Netgear ProSafe 24+2 Gigabit Switch with PoE
1 Gigabit output w/12 PoE 100Base-TX
(www.netgear.com)
"D-Link Web Smart #DES-1316 (POE Switch/Hub)
